Warning

Running Patroni on memory-restricted systems with Python 3.11+

If you run Patroni on a system with strict memory limits, for example with vm.overcommit_memory=2 (recommended for PostgreSQL), and use Python 3.11 or newer, you may observe unexpected behavior:

• Patroni appears healthy
• PostgreSQL continues to run
• Patroni REST API becomes unresponsive
• The operating system reports that Patroni is listening on the REST API port
• Patroni logs look normal; however, following messages may appear once: Exception ignored in thread started by: <object repr() failed>, MemoryError
• Kernel logs may contain messages such as not enough memory for the allocation

This behavior is caused by a bug in Python 3.11+. Under strict memory conditions, starting a new thread may hang indefinitely when there is not enough free memory.

Recommended solution

Recent Patroni releases (4.1.1+, 4.0.8+) reduce the impact of this issue by starting all required threads early during startup, before the system is under memory pressure.

Additional recommendations (Linux, glibc)

When running with vm.overcommit_memory=2 (recommended for PostgreSQL), we also recommend starting Patroni with the following environment variables configured:

• MALLOC_ARENA_MAX=1 - reduces the amount of virtual memory allocated by glibc for multi-threaded applications
• PG_MALLOC_ARENA_MAX= - resets the value of MALLOC_ARENA_MAX for PostgreSQL processes started by Patroni.

In addition, you may tune the following Patroni configuration parameters:

• thread_stack_size - stack size used for threads started by Patroni. Lowering this value reduces memory usage of the Patroni process. The default value set by Patroni is 512kB. Increase thread_stack_size if Patroni experiences stack-related crashes; otherwise the default value is sufficient.
• thread_pool_size - size of the thread pool used by Patroni for asynchronous tasks and REST API communication with other members during leader race or failsafe checks. The default value is 5, which is sufficient for three-node clusters.
• restapi.thread_pool_size - size of the thread pool used to process REST API requests. The default value is 5, allowing up to five parallel REST API requests. Note that requests involving SQL queries are effectively serialized because a single database connection is used, so increasing this value typically provides no benefit.

---

Patroni is a template for high availability (HA) PostgreSQL solutions using Python. For maximum accessibility, Patroni supports a variety of distributed configuration stores like ZooKeeper, etcd, Consul or Kubernetes. Database engineers, DBAs, DevOps engineers, and SREs who are looking to quickly deploy HA PostgreSQL in datacenters — or anywhere else — will hopefully find it useful.

We call Patroni a “template” because it is far from being a one-size-fits-all or plug-and-play replication system. It will have its own caveats. Use wisely. There are many ways to run high availability with PostgreSQL; for a list, see the PostgreSQL Documentation.

Currently supported PostgreSQL versions: 9.3 to 18.

Note to Citus users: Starting from 3.0 Patroni nicely integrates with the Citus database extension to Postgres. Please check the Citus support page in the Patroni documentation for more info about how to use Patroni high availability together with a Citus distributed cluster.

Note to Kubernetes users: Patroni can run natively on top of Kubernetes. Take a look at the Kubernetes chapter of the Patroni documentation.

1 - Introduction

Source: https://patroni.readthedocs.io/en/latest/README.html

Patroni is a template for high availability (HA) PostgreSQL solutions using Python. Patroni originated as a fork of Governor, the project from Compose. It includes plenty of new features.

For additional background info, see:

• PostgreSQL HA with Kubernetes and Patroni, talk by Josh Berkus at KubeCon 2016 (video)
• Feb. 2016 Zalando Tech blog post

Development Status

Patroni is in active development and accepts contributions. See our Contributing section below for more details.

We report new releases information here.

Technical Requirements/Installation

Go here for guidance on installing and upgrading Patroni on various platforms.

Planning the Number of PostgreSQL Nodes

Patroni/PostgreSQL nodes are decoupled from DCS nodes (except when Patroni implements RAFT on its own) and therefore there is no requirement on the minimal number of nodes. Running a cluster consisting of one primary and one standby is perfectly fine. You can add more standby nodes later.

2-node clusters (primary + standby) are common and provide automatic failover with high availability. Note that during failover, you’ll temporarily have no redundancy until the failed node rejoins.

DCS requirements: Your DCS (etcd, ZooKeeper, Consul) has to run with 3 or 5 nodes for proper consensus and fault tolerance. A single DCS cluster can store information for hundreds or thousands of Patroni clusters using different namespace/scope combinations.

Running and Configuring

The following section assumes Patroni repository as being cloned from https://github.com/patroni/patroni. Namely, you will need example configuration files postgres0.yml and postgres1.yml. If you installed Patroni with pip, you can obtain those files from the git repository and replace ./patroni.py below with patroni command.

To get started, do the following from different terminals: :

> etcd --data-dir=data/etcd --enable-v2=true
> ./patroni.py postgres0.yml
> ./patroni.py postgres1.yml

You will then see a high-availability cluster start up. Test different settings in the YAML files to see how the cluster’s behavior changes. Kill some of the components to see how the system behaves.

Add more postgres*.yml files to create an even larger cluster.

Patroni provides an HAProxy configuration, which will give your application a single endpoint for connecting to the cluster’s leader. To configure, run:

> haproxy -f haproxy.cfg

> psql --host 127.0.0.1 --port 5000 postgres

YAML Configuration

Go here for comprehensive information about settings for etcd, consul, and ZooKeeper. And for an example, see postgres0.yml.

Environment Configuration

Go here for comprehensive information about configuring(overriding) settings via environment variables.

Replication Choices

Patroni uses Postgres’ streaming replication, which is asynchronous by default. Patroni’s asynchronous replication configuration allows for maximum_lag_on_failover settings. This setting ensures failover will not occur if a follower is more than a certain number of bytes behind the leader. This setting should be increased or decreased based on business requirements. It’s also possible to use synchronous replication for better durability guarantees. See replication modes documentation for details.

Applications Should Not Use Superusers

When connecting from an application, always use a non-superuser. Patroni requires access to the database to function properly. By using a superuser from an application, you can potentially use the entire connection pool, including the connections reserved for superusers, with the superuser_reserved_connections setting. If Patroni cannot access the Primary because the connection pool is full, behavior will be undesirable.

Testing Your HA Solution

Testing an HA solution is a time-consuming process, with many variables. This is particularly true considering a cross-platform application. You need a trained system administrator or a consultant to do this work. It is not something we can cover in depth in the documentation.

That said, here are some pieces of your infrastructure you should be sure to test:

• Network (the network in front of your system as well as the NICs $$physical or virtual$$themselves)
• Disk IO
• file limits (nofile in Linux)
• RAM. Even if you have oomkiller turned off, the unavailability of RAM could cause issues.
• CPU
• Virtualization Contention (overcommitting the hypervisor)
• Any cgroup limitation (likely to be related to the above)
• kill -9 of any postgres process (except postmaster!). This is a decent simulation of a segfault.

One thing that you should not do is run kill -9 on a postmaster process. This is because doing so does not mimic any real life scenario. If you are concerned your infrastructure is insecure and an attacker could run kill -9, no amount of HA process is going to fix that. The attacker will simply kill the process again, or cause chaos in another way.

2 - Installation

Source: https://patroni.readthedocs.io/en/latest/installation.html

Pre-requirements for Mac OS

To install requirements on a Mac, run the following:

brew install postgresql etcd haproxy libyaml python

Psycopg

Starting from psycopg2-2.8 the binary version of psycopg2 will no longer be installed by default. Installing it from the source code requires C compiler and postgres+python dev packages. Since in the python world it is not possible to specify dependency as psycopg2 OR psycopg2-binary you will have to decide how to install it.

There are a few options available:

1. Use the package manager from your distro

sudo apt-get install python3-psycopg2  # install psycopg2 module on Debian/Ubuntu
sudo yum install python3-psycopg2      # install psycopg2 on RedHat/Fedora/CentOS

2. Specify one of psycopg, psycopg2, or psycopg2-binary in the list of dependencies when installing Patroni with pip.

General installation for pip

Patroni can be installed with pip:

pip install patroni[dependencies]

where dependencies can be either empty, or consist of one or more of the following:

etcd or etcd3
python-etcd module in order to use Etcd as Distributed Configuration Store (DCS)

consul
py-consul module in order to use Consul as DCS

zookeeper
kazoo module in order to use Zookeeper as DCS

exhibitor
kazoo module in order to use Exhibitor as DCS (same dependencies as for Zookeeper)

kubernetes
kubernetes module in order to use Kubernetes as DCS in Patroni

raft
pysyncobj module in order to use python Raft implementation as DCS

aws
boto3 in order to use AWS callbacks

jsonlogger
python-json-logger module in order to enable logging in json format

systemd
systemd-python in order to use sd_notify integration

all
all of the above (except psycopg family)

psycopg3
psycopg\[binary\]\>=3.0.0 module

psycopg2
psycopg2\>=2.5.4 module

psycopg2-binary
psycopg2-binary module

For example, the command in order to install Patroni together with psycopg3, dependencies for Etcd as a DCS, and AWS callbacks is:

pip install patroni[psycopg3,etcd3,aws]

Note that external tools to call in the replica creation or custom bootstrap scripts (i.e. WAL-E) should be installed independently of Patroni.

Package installation on Linux

Patroni packages may be available for your operating system, produced by the Postgres community for:

• RHEL, RockyLinux, AlmaLinux;
• Debian and Ubuntu;
• SUSE Enterprise Linux.

You can also find packages for direct dependencies of Patroni, like python modules that might not be available in the official operating system repositories.

For more information see the PGDG repository documentation.

If you are on a RedHat Enterprise Linux derivative operating system you may also require packages from EPEL, see EPEL repository documentation.

Once you have installed the PGDG repository for your OS you can install patroni.

Installing on Debian derivatives

With PGDG repo installed, see above, install Patroni via apt run:

apt-get install patroni

Installing on RedHat derivatives

With PGDG repo installed, see above, install patroni with an etcd DCS via dnf on RHEL 9 (and derivatives) run:

dnf install patroni patroni-etcd

You can install etcd from PGDG if your RedHat derivative distribution does not provide packages. On the nodes that will host the DCS run:

dnf install 'dnf-command(config-manager)'
dnf config-manager --enable pgdg-rhel9-extras
dnf install etcd

You can replace the version of RHEL with 8 in the repo to make pgdg-rhel8-extras if needed. The repo name is still pgdg-rhelN-extras on RockyLinux, AlmaLinux, Oracle Linux, etc…

Installing on SUSE Enterprise Linux

You might need to enable the SUSE PackageHub repositories for some dependencies. see SUSE PackageHub documentation.

For SLES 15 with PGDG repo installed, see above, you can install patroni using:

zypper install patroni patroni-etcd

With the SUSE PackageHub repo enabled you can also install etcd:

SUSEConnect -p PackageHub/15.5/x86_64
zypper install etcd

Upgrading

Upgrading patroni is a very simple process, just update the software installation and restart the Patroni daemon on each node in the cluster.

However, restarting the Patroni daemon will result in a Postgres database restart. In some situations this may cause a failover of the primary node in your cluster, therefore it is recommended to put the cluster into maintenance mode until the Patroni daemon restart has been completed.

To put the cluster in maintenance mode, run the following command on one of the patroni nodes:

patronictl pause --wait

Then on each node in the cluster, perform the package upgrade required for your OS:

apt-get update && apt-get install patroni patroni-etcd

Restart the patroni daemon process on each node:

systemctl restart patroni

Then finally resume monitoring of Postgres with patroni to take it out of maintenance mode:

patronictl resume --wait

The cluster will now be full operational with the new version of Patroni.

3 - Patroni configuration

Source: https://patroni.readthedocs.io/en/latest/patroni_configuration.html

There are 3 types of Patroni configuration:

• Global dynamic configuration.
  These options are stored in the DCS (Distributed Configuration Store) and applied on all cluster nodes. Dynamic configuration can be set at any time using patronictl_edit_config tool or Patroni REST API. If the options changed are not part of the startup configuration, they are applied asynchronously (upon the next wake up cycle) to every node, which gets subsequently reloaded. If the node requires a restart to apply the configuration (for PostgreSQL parameters with context postmaster, if their values have changed), a special flag pending_restart indicating this is set in the members.data JSON. Additionally, the node status indicates this by showing "restart_pending": true.

• Local configuration file (patroni.yml).
  These options are defined in the configuration file and take precedence over dynamic configuration. patroni.yml can be changed and reloaded at runtime (without restart of Patroni) by sending SIGHUP to the Patroni process, performing POST /reload REST-API request or executing patronictl_reload. Local configuration can be either a single YAML file or a directory. When it is a directory, all YAML files in that directory are loaded one by one in sorted order. In case a key is defined in multiple files, the occurrence in the last file takes precedence.

• Environment configuration.
  It is possible to set/override some of the “Local” configuration parameters with environment variables. Environment configuration is very useful when you are running in a dynamic environment and you don’t know some of the parameters in advance (for example it’s not possible to know your external IP address when you are running inside docker).

Important rules

PostgreSQL parameters controlled by Patroni

Some of the PostgreSQL parameters must hold the same values on the primary and the replicas. For those, values set either in the local patroni configuration files or via the environment variables take no effect. To alter or set their values one must change the shared configuration in the DCS. Below is the actual list of such parameters together with the default and minimal values:

• max_connections: default value 100, minimal value 25
• max_locks_per_transaction: default value 64, minimal value 32
• max_worker_processes: default value 8, minimal value 2
• max_prepared_transactions: default value 0, minimal value 0
• wal_level: default value hot_standby, accepted values: hot_standby, replica, logical
• track_commit_timestamp: default value off

For the parameters below, PostgreSQL does not require equal values among the primary and all the replicas. However, considering the possibility of a replica to become the primary at any time, it doesn’t really make sense to set them differently; therefore, Patroni restricts setting their values to the dynamic configuration.

• max_wal_senders: default value 10, minimal value 3
• max_replication_slots: default value 10, minimal value 4
• wal_keep_segments: default value 8, minimal value 1
• wal_keep_size: default value 128MB, minimal value 16MB
• wal_log_hints: on

These parameters are validated to ensure they are sane, or meet a minimum value.

There are some other Postgres parameters controlled by Patroni:

• listen_addresses - is set either from postgresql.listen or from PATRONI_POSTGRESQL_LISTEN environment variable
• port - is set either from postgresql.listen or from PATRONI_POSTGRESQL_LISTEN environment variable
• cluster_name - is set either from scope or from PATRONI_SCOPE environment variable
• hot_standby: on

To be on the safe side parameters from the above lists are written into postgresql.conf, and passed as a list of arguments to the postgres which gives them the highest precedence (except wal_keep_segments and wal_keep_size), even above ALTER SYSTEM

There also are some parameters like postgresql.listen, postgresql.data_dir that can be set only locally, i.e. in the Patroni config file or via configuration variable. In most cases the local configuration will override the dynamic configuration.

When applying the local or dynamic configuration options, the following actions are taken:

• The node first checks if there is a postgresql.base.conf file or if the custom_conf parameter is set.
• If the custom_conf parameter is set, the file it specifies is used as the base configuration, ignoring postgresql.base.conf and postgresql.conf.
• If the custom_conf parameter is not set and postgresql.base.conf exists, it contains the renamed “original” configuration and is used as the base configuration.
• If there is no custom_conf nor postgresql.base.conf, the original postgresql.conf is renamed to postgresql.base.conf and used as the base configuration.
• The dynamic options (with the exceptions above) are dumped into the postgresql.conf and an include is set in postgresql.conf to the base configuration (either postgresql.base.conf or the file at custom_conf). Therefore, we would be able to apply new options without re-reading the configuration file to check if the include is present or not.
• Some parameters that are essential for Patroni to manage the cluster are overridden using the command line.
• If an option that requires restart is changed (we should look at the context in pg_settings and at the actual values of those options), a pending_restart flag is set on that node. This flag is reset on any restart.

The parameters would be applied in the following order (run-time are given the highest priority):

1. load parameters from file postgresql.base.conf (or from a custom_conf file, if set)
2. load parameters from file postgresql.conf
3. load parameters from file postgresql.auto.conf
4. run-time parameter using -o --name=value

This allows configuration for all the nodes (2), configuration for a specific node using ALTER SYSTEM (3) and ensures that parameters essential to the running of Patroni are enforced (4), as well as leaves room for configuration tools that manage postgresql.conf directly without involving Patroni (1).

PostgreSQL parameters that touch shared memory

PostgreSQL has some parameters that determine the size of the shared memory used by them:

• max_connections
• max_prepared_transactions
• max_locks_per_transaction
• max_wal_senders
• max_worker_processes

Changing these parameters require a PostgreSQL restart to take effect, and their shared memory structures cannot be smaller on the standby nodes than on the primary node.

As explained before, Patroni restrict changing their values through dynamic configuration, which usually consists of:

1. Applying changes through patronictl_edit_config (or via REST API /config endpoint)
2. Restarting nodes through patronictl_restart (or via REST API /restart endpoint)

Note: please keep in mind that you should perform a restart of the PostgreSQL nodes through patronictl_restart command, or via REST API /restart endpoint. An attempt to restart PostgreSQL by restarting the Patroni daemon, e.g. by executing systemctl restart patroni, can cause a failover to occur in the cluster, if you are restarting the primary node.

However, as those settings manage shared memory, some extra care should be taken when restarting the nodes:

• If you want to increase the value of any of those settings:

  1. Restart all standbys first
  2. Restart the primary after that

• If you want to decrease the value of any of those settings:

  1. Restart the primary first
  2. Restart all standbys after that

Note: if you attempt to restart all nodes in one go after decreasing the value of any of those settings, Patroni will ignore the change and restart the standby with the original setting value, thus requiring that you restart the standbys again later. Patroni does that to prevent the standby to enter in an infinite crash loop, because PostgreSQL quits with a FATAL message if you attempt to set any of those parameters to a value lower than what is visible in pg_controldata on the Standby node. In other words, we can only decrease the setting on the standby once its pg_controldata is up-to-date with the primary in regards to these changes on the primary.

More information about that can be found at PostgreSQL Administrator’s Overview.

Patroni configuration parameters

Also the following Patroni configuration options can be changed only dynamically:

• ttl: 30
• loop_wait: 10
• retry_timeout: 10
• maximum_lag_on_failover: 1048576
• max_timelines_history: 0
• check_timeline: false
• postgresql.use_slots: true

Upon changing these options, Patroni will read the relevant section of the configuration stored in DCS and change its run-time values.

Patroni nodes are dumping the state of the DCS options to disk upon for every change of the configuration into the file patroni.dynamic.json located in the Postgres data directory. Only the leader is allowed to restore these options from the on-disk dump if these are completely absent from the DCS or if they are invalid.

Configuration generation and validation

Patroni provides command-line interfaces for a Patroni local configuration generation and validation. Using the patroni executable you can:

• Create a sample local Patroni configuration;
• Create a Patroni configuration file for the locally running PostgreSQL instance (e.g. as a preparation step for the Patroni integration);
• Validate a given Patroni configuration file.

Sample Patroni configuration

patroni --generate-sample-config [configfile]

Description

Generate a sample Patroni configuration file in yaml format. Parameter values are defined using the Environment configuration, otherwise, if not set, the defaults used in Patroni or the #FIXME string for the values that should be later defined by the user.

Some default values are defined based on the local setup:

• postgresql.listen: the IP address returned by gethostname call for the current machine’s hostname and the standard 5432 port.
• postgresql.connect_address: the IP address returned by gethostname call for the current machine’s hostname and the standard 5432 port.
• postgresql.authentication.rewind: is only defined if the PostgreSQL version can be defined from the binary and the version is 11 or later.
• restapi.listen: IP address returned by gethostname call for the current machine’s hostname and the standard 8008 port.
• restapi.connect_address: IP address returned by gethostname call for the current machine’s hostname and the standard 8008 port.

Parameters

configfile - full path to the configuration file used to store the result. If not provided, the result is sent to stdout.

Patroni configuration for a running instance

patroni --generate-config [--dsn DSN] [configfile]

Description

Generate a Patroni configuration in yaml format for the locally running PostgreSQL instance. Either the provided DSN (takes precedence) or PostgreSQL environment variables will be used for the PostgreSQL connection. If the password is not provided, it should be entered via prompt.

All the non-internal GUCs defined in the source Postgres instance, independently if they were set through a configuration file, through the postmaster command-line, or through environment variables, will be used as the source for the following Patroni configuration parameters:

• scope: cluster_name GUC value;
• postgresql.listen: listen_addresses and port GUC values;
• postgresql.datadir: data_directory GUC value;
• postgresql.parameters: archive_command, restore_command, archive_cleanup_command, recovery_end_command, ssl_passphrase_command, hba_file, ident_file, config_file GUC values;
• bootstrap.dcs: all other gathered PostgreSQL GUCs.

If scope, postgresql.listen or postgresql.datadir is not set from the Postgres GUCs, the respective Environment configuration value is used.

Other rules applied for the values definition:

• name: PATRONI_NAME environment variable value if set, otherwise the current machine’s hostname.
• postgresql.bin_dir: path to the Postgres binaries gathered from the running instance.
• postgresql.connect_address: the IP address returned by gethostname call for the current machine’s hostname and the port used for the instance connection or the port GUC value.
• postgresql.authentication.superuser: the configuration used for the instance connection;
• postgresql.pg_hba: the lines gathered from the source instance’s hba_file.
• postgresql.pg_ident: the lines gathered from the source instance’s ident_file.
• restapi.listen: IP address returned by gethostname call for the current machine’s hostname and the standard 8008 port.
• restapi.connect_address: IP address returned by gethostname call for the current machine’s hostname and the standard 8008 port.

Other parameters defined using Environment configuration are also included into the configuration.

Parameters

configfile
Full path to the configuration file used to store the result. If not provided, result is sent to stdout.

dsn
Optional DSN string for the local PostgreSQL instance to get GUC values from.

Validate Patroni configuration

patroni --validate-config [configfile] [--ignore-listen-port | -i]

Description

Validate the given Patroni configuration and print the information about the failed checks.

Parameters

configfile
Full path to the configuration file to check. If not given or file does not exist, will try to read from the PATRONI_CONFIG_VARIABLE environment variable or, if not set, from the Patroni environment variables.

--ignore-listen-port | -i
Optional flag to ignore bind failures for listen ports that are already in use when validating the configfile.

--print | -p
Optional flag to print out local configuration (including environment configuration overrides) after it has been successfully validated.

3.1 - Dynamic Configuration Settings

Source: https://patroni.readthedocs.io/en/latest/dynamic_configuration.html

Dynamic configuration is stored in the DCS (Distributed Configuration Store) and applied on all cluster nodes.

In order to change the dynamic configuration you can use either patronictl_edit_config tool or Patroni REST API.

• loop_wait: the number of seconds the loop will sleep. Default value: 10, minimum possible value: 1
• ttl: the TTL to acquire the leader lock (in seconds). Think of it as the length of time before initiation of the automatic failover process. Default value: 30, minimum possible value: 20
• retry_timeout: timeout for DCS and PostgreSQL operation retries (in seconds). DCS or network issues shorter than this will not cause Patroni to demote the leader. Default value: 10, minimum possible value: 3

loop_wait + 2 * retry_timeout <= ttl

• maximum_lag_on_failover: the maximum bytes a follower may lag to be able to participate in leader election.
• primary_race_backoff: postpones leader race on standbys by primary_race_backoff seconds if WAL replication from the primary is still advancing. It allows to minimize unnecessary failovers caused by briefly unresponsive Patroni. Default value: 0 (disabled).
• maximum_lag_on_syncnode: the maximum bytes a synchronous follower may lag before it is considered as an unhealthy candidate and swapped by healthy asynchronous follower. Patroni utilize the max replica lsn if there is more than one follower, otherwise it will use leader’s current wal lsn. Default is -1, Patroni will not take action to swap synchronous unhealthy follower when the value is set to 0 or below. Please set the value high enough so Patroni won’t swap synchrounous follower frequently during high transaction volume.
• max_timelines_history: maximum number of timeline history items kept in DCS. Default value: 0. When set to 0, it keeps the full history in DCS.
• primary_start_timeout: the amount of time a primary is allowed to recover from failures before failover is triggered (in seconds). Default is 300 seconds. When set to 0 failover is done immediately after a crash is detected if possible. When using asynchronous replication a failover can cause lost transactions. Worst case failover time for primary failure is: loop_wait + primary_start_timeout + loop_wait, unless primary_start_timeout is zero, in which case it’s just loop_wait. Set the value according to your durability/availability tradeoff.
• primary_stop_timeout: The number of seconds Patroni is allowed to wait when stopping Postgres and effective only when synchronous_mode is enabled. When set to > 0 and the synchronous_mode is enabled, Patroni sends SIGKILL to the postmaster if the stop operation is running for more than the value set by primary_stop_timeout. Set the value according to your durability/availability tradeoff. If the parameter is not set or set <= 0, primary_stop_timeout does not apply.
• synchronous_mode: turns on synchronous replication mode. Possible values: off, on, quorum. In this mode the leader takes care of management of synchronous_standby_names, and only the last known leader, or one of synchronous replicas, are allowed to participate in leader race. Synchronous mode makes sure that successfully committed transactions will not be lost at failover, at the cost of losing availability for writes when Patroni cannot ensure transaction durability. See replication modes documentation for details.
• synchronous_mode_strict: prevents disabling synchronous replication if no synchronous replicas are available, blocking all client writes to the primary. When this option is set and no eligible replica is streaming, Patroni keeps synchronous_standby_names pointing to the last known synchronous nodes from the /sync DCS key, or uses the internal placeholder __patroni_strict_sync_replica_placeholder__ when no prior sync state exists. The node name in patroni.yaml must not be set to __patroni_strict_sync_replica_placeholder__. See replication modes documentation for details.
• synchronous_node_count: if synchronous_mode is enabled, this parameter is used by Patroni to manage the precise number of synchronous standby instances and adjusts the state in DCS and the synchronous_standby_names parameter in PostgreSQL as members join and leave. If the parameter is set to a value higher than the number of eligible nodes, it will be automatically adjusted. Defaults to 1.
• failsafe_mode: Enables DCS Failsafe Mode. Defaults to false.
• postgresql:
  • use_pg_rewind: whether or not to use pg_rewind. Defaults to false. Note that either the cluster must be initialized with data page checksums (--data-checksums option for initdb) and/or wal_log_hints must be set to on, or pg_rewind will not work.
  • use_slots: whether or not to use replication slots. Defaults to true on PostgreSQL 9.4+.
  • recovery_conf: additional configuration settings written to recovery.conf when configuring follower. There is no recovery.conf anymore in PostgreSQL 12, but you may continue using this section, because Patroni handles it transparently.
  • parameters: configuration parameters (GUCs) for Postgres in format {max_connections: 100, wal_level: "replica", max_wal_senders: 10, wal_log_hints: "on"}. Many of these are required for replication to work.
  • parameters_primary: (optional) role-specific parameter overrides for primary. These values are merged with and override the base parameters.
  • parameters_replica: (optional) role-specific parameter overrides for replica. These values are merged with and override the base parameters.
  • parameters_standby_leader: (optional) role-specific parameter overrides for standby_leader. These values are merged with and override the base parameters.
  • pg_hba: list of lines that Patroni will use to generate pg_hba.conf. Patroni ignores this parameter if hba_file PostgreSQL parameter is set to a non-default value.
    • - host all all 0.0.0.0/0 md5
    • - host replication replicator 127.0.0.1/32 md5: A line like this is required for replication.
  • pg_hba_primary: (optional) role-specific pg_hba entries for primary. These completely replace pg_hba (no merging). If not defined, pg_hba is used.
  • pg_hba_replica: (optional) role-specific pg_hba entries for replica. These completely replace pg_hba (no merging). If not defined, pg_hba is used.
  • pg_hba_standby_leader: (optional) role-specific pg_hba entries for standby_leader. These completely replace pg_hba (no merging). If not defined, pg_hba is used.
  • pg_ident: list of lines that Patroni will use to generate pg_ident.conf. Patroni ignores this parameter if ident_file PostgreSQL parameter is set to a non-default value.
    • - mapname1 systemname1 pguser1
    • - mapname1 systemname2 pguser2
  • pg_ident_primary: (optional) role-specific pg_ident entries for primary. These completely replace pg_ident (no merging). If not defined, pg_ident is used.
  • pg_ident_replica: (optional) role-specific pg_ident entries for replica. These completely replace pg_ident (no merging). If not defined, pg_ident is used.
  • pg_ident_standby_leader: (optional) role-specific pg_ident entries for standby_leader. These completely replace pg_ident (no merging). If not defined, pg_ident is used.
• standby_cluster: if this section is defined, we want to bootstrap a standby cluster.
  • host: an address of remote node
  • port: a port of remote node
  • primary_slot_name: which slot on the remote node to use for replication. This parameter is optional, the default value is derived from the instance name (see function slot_name_from_member_name).
  • create_replica_methods: an ordered list of methods that can be used to bootstrap standby leader from the remote primary, can be different from the list defined in postgresql_settings
  • restore_command: command to restore WAL records from the remote primary to nodes in a standby cluster, can be different from the list defined in postgresql_settings
  • archive_cleanup_command: cleanup command for standby leader
  • recovery_min_apply_delay: how long to wait before actually apply WAL records on a standby leader
• member_slots_ttl: retention time of physical replication slots for replicas when they are shut down. Default value: 30min. Set it to 0 if you want to keep the old behavior (when the member key expires from DCS, the slot is immediately removed). The feature works only starting from PostgreSQL 11.
• slots: define permanent replication slots. These slots will be preserved during switchover/failover. Permanent slots that don’t exist will be created by Patroni. With PostgreSQL 11 onwards permanent physical slots are created on all nodes and their position is advanced every loop_wait seconds. For PostgreSQL versions older than 11 permanent physical replication slots are maintained only on the current primary. The logical slots are copied from the primary to a standby with restart, and after that their position advanced every loop_wait seconds (if necessary). Copying logical slot files performed via libpq connection and using either rewind or superuser credentials (see postgresql.authentication section). There is always a chance that the logical slot position on the replica is a bit behind the former primary, therefore application should be prepared that some messages could be received the second time after the failover. The easiest way of doing so - tracking confirmed_flush_lsn. Enabling permanent replication slots requires postgresql.use_slots to be set to true. If there are permanent logical replication slots defined Patroni will automatically enable the hot_standby_feedback. Since the failover of logical replication slots is unsafe on PostgreSQL 9.6 and older and PostgreSQL version 10 is missing some important functions, the feature only works with PostgreSQL 11+.
  • my_slot_name: the name of the permanent replication slot. If the permanent slot name matches with the name of the current node it will not be created on this node. If you add a permanent physical replication slot which name matches the name of a Patroni member, Patroni will ensure that the slot that was created is not removed even if the corresponding member becomes unresponsive, situation which would normally result in the slot’s removal by Patroni. Although this can be useful in some situations, such as when you want replication slots used by members to persist during temporary failures or when importing existing members to a new Patroni cluster (see Convert a Standalone to a Patroni Cluster for details), caution should be exercised by the operator that these clashes in names are not persisted in the DCS, when the slot is no longer required, due to its effect on normal functioning of Patroni.
    • type: slot type. Could be physical or logical. If the slot is logical, you have to additionally define database and plugin. If the slot is physical, you can optionally define cluster_type.
    • database: the database name where logical slots should be created.
    • plugin: the plugin name for the logical slot.
    • cluster_type: the type of cluster (primary or standby) the slot should only be created on, otherwise it will not be created or an already existing slot will be dropped.
• ignore_slots: list of sets of replication slot properties for which Patroni should ignore matching slots. This configuration/feature/etc. is useful when some replication slots are managed outside of Patroni. Any subset of matching properties will cause a slot to be ignored.
  • name: the name of the replication slot.
  • type: slot type. Can be physical or logical. If the slot is logical, you may additionally define database and/or plugin.
  • database: the database name (when matching a logical slot).
  • plugin: the logical decoding plugin (when matching a logical slot).

Note: slots is a hashmap while ignore_slots is an array. For example:

slots:
  permanent_logical_slot_name:
    type: logical
    database: my_db
    plugin: test_decoding
  permanent_physical_slot_name:
    type: physical
  ...
ignore_slots:
  - name: ignored_logical_slot_name
    type: logical
    database: my_db
    plugin: test_decoding
  - name: ignored_physical_slot_name
    type: physical
  ...

Note: When running PostgreSQL v11 or newer Patroni maintains physical replication slots on all nodes that could potentially become a leader, so that replica nodes keep WAL segments reserved if they are potentially required by other nodes. In case the node is absent and its member key in DCS gets expired, the corresponding replication slot is dropped after member_slots_ttl (default value is 30min). You can increase or decrease retention based on your needs. Alternatively, if your cluster topology is static (fixed number of nodes that never change their names) you can configure permanent physical replication slots with names corresponding to the names of the nodes to avoid slots removal and recycling of WAL files while replica is temporarily down:

slots:
  node_name1:
    type: physical
  node_name2:
    type: physical
  node_name3:
    type: physical
  ...

3.2 - YAML Configuration Settings

Source: https://patroni.readthedocs.io/en/latest/yaml_configuration.html

Global/Universal

• thread_pool_size: size of thread pool used by Patroni to execute asynchronous tasks and communicate via REST API with other members during leader race or failsafe checks. Minimal value is 5, default value is 5.
• thread_stack_size: specifies the stack size to be used for threads started by Patroni. Value must be aligned by 64kB. Minimal value is 64kB, default value (set by Patroni) is 512kB.
• name: the name of the host. Must be unique for the cluster. The value __patroni_strict_sync_replica_placeholder__ is reserved for internal use by Patroni and cannot be used as a node name.
• namespace: path within the configuration store where Patroni will keep information about the cluster. Default value: “/service”
• scope: cluster name

Log

• type: sets the format of logs. Can be either plain or json. To use json format, you must have the jsonlogger installed. The default value is plain.
• level: sets the general logging level. Default value is INFO (see the docs for Python logging)
• traceback_level: sets the level where tracebacks will be visible. Default value is ERROR. Set it to DEBUG if you want to see tracebacks only if you enable log.level=DEBUG.
• format: sets the log formatting string. If the log type is plain, the log format should be a string. Refer to the LogRecord attributes for available attributes. If the log type is json, the log format can be a list in addition to a string. Each list item should correspond to LogRecord attributes. Be cautious that only the field name is required, and the %( and ) should be omitted. If you wish to print a log field with a different key name, use a dictionary where the dictionary key is the log field, and the value is the name of the field you want to be printed in the log. Default value is %(asctime)s %(levelname)s: %(message)s
• dateformat: sets the datetime formatting string. (see the formatTime() documentation)
• static_fields: add additional fields to the log. This option is only available when the log type is set to json.
• max_queue_size: Patroni is using two-step logging. Log records are written into the in-memory queue and there is a separate thread which pulls them from the queue and writes to stderr or file. The maximum size of the internal queue is limited by default by 1000 records, which is enough to keep logs for the past 1h20m.
• dir: Directory to write application logs to. The directory must exist and be writable by the user executing Patroni. If you set this value, the application will retain 4 25MB logs by default. You can tune those retention values with file_num and file_size (see below).
• mode: Permissions for log files (for example, 0644). If not specified, permissions will be set based on the current umask value.
• file_num: The number of application logs to retain.
• file_size: Size of patroni.log file (in bytes) that triggers a log rolling.
• loggers: This section allows redefining logging level per python module
  • patroni.postmaster: WARNING
  • urllib3: DEBUG
• deduplicate_heartbeat_logs: If set to true, successive heartbeat logs that are identical shall not be output. Default value is false.

Here is an example of how to config patroni to log in json format.

log:
   type: json
   format:
      - message
      - module
      - asctime: '@timestamp'
      - levelname: level
   static_fields:
      app: patroni

Bootstrap configuration

• bootstrap:

  • dcs: This section will be written into /<namespace>/<scope>/config of the given configuration store after initializing the new cluster. The global dynamic configuration for the cluster. You can put any of the parameters described in the Dynamic Configuration settings under bootstrap.dcs and after Patroni has initialized (bootstrapped) the new cluster, it will write this section into /<namespace>/<scope>/config of the configuration store.

  • method: custom script to use for bootstrapping this cluster.

    See custom bootstrap methods documentation for details. When initdb is specified revert to the default initdb command. initdb is also triggered when no method parameter is present in the configuration file.

  • initdb: (optional) list options to be passed on to initdb.

    • - data-checksums: Must be enabled when pg_rewind is needed on 9.3.
    • - encoding: UTF8: default encoding for new databases.
    • - locale: UTF8: default locale for new databases.

  • post_bootstrap or post_init: An additional script that will be executed after initializing the cluster. The script receives a connection string URL (with the cluster superuser as a user name). The PGPASSFILE variable is set to the location of pgpass file.

Citus

Enables integration Patroni with Citus. If configured, Patroni will take care of registering Citus worker nodes on the coordinator. You can find more information about Citus support here.

• group: the Citus group id, integer. Use 0 for coordinator and 1, 2, etc… for workers
• database: the database where citus extension should be created. Must be the same on the coordinator and all workers. Currently only one database is supported.

Consul

Most of the parameters are optional, but you have to specify one of the host or url

• host: the host:port for the Consul local agent.
• url: url for the Consul local agent, in format: http(s)://host:port.
• port: (optional) Consul port.
• scheme: (optional) http or https, defaults to http.
• token: (optional) ACL token.
• verify: (optional) whether to verify the SSL certificate for HTTPS requests.
• cacert: (optional) The ca certificate. If present it will enable validation.
• cert: (optional) file with the client certificate.
• key: (optional) file with the client key. Can be empty if the key is part of cert.
• dc: (optional) Datacenter to communicate with. By default the datacenter of the host is used.
• consistency: (optional) Select consul consistency mode. Possible values are default, consistent, or stale (more details in consul API reference)
• checks: (optional) list of Consul health checks used for the session. By default an empty list is used.
• register_service: (optional) whether or not to register a service with the name defined by the scope parameter and the tag master, primary, replica, or standby-leader depending on the node’s role. Defaults to false.
• service_tags: (optional) additional static tags to add to the Consul service apart from the role (primary/replica/standby-leader). By default an empty list is used.
• service_check_interval: (optional) how often to perform health check against registered url. Defaults to ‘5s’.
• service_check_tls_server_name: (optional) override SNI host when connecting via TLS, see also consul agent check API reference.

The token needs to have the following ACL permissions:

service_prefix "${scope}" {
    policy = "write"
}
key_prefix "${namespace}/${scope}" {
    policy = "write"
}
session_prefix "" {
    policy = "write"
}

Etcd

Most of the parameters are optional, but you have to specify one of the host, hosts, url, proxy or srv

• host: the host:port for the etcd endpoint.
• hosts: list of etcd endpoint in format host1:port1,host2:port2,etc… Could be a comma separated string or an actual yaml list.
• use_proxies: If this parameter is set to true, Patroni will consider hosts as a list of proxies and will not perform a topology discovery of etcd cluster.
• url: url for the etcd.
• proxy: proxy url for the etcd. If you are connecting to the etcd using proxy, use this parameter instead of url.
• srv: Domain to search the SRV record(s) for cluster autodiscovery. Patroni will try to query these SRV service names for specified domain (in that order until first success): _etcd-client-ssl, _etcd-client, _etcd-ssl, _etcd, _etcd-server-ssl, _etcd-server. If SRV records for _etcd-server-ssl or _etcd-server are retrieved then ETCD peer protocol is used do query ETCD for available members. Otherwise hosts from SRV records will be used.
• srv_suffix: Configures a suffix to the SRV name that is queried during discovery. Use this flag to differentiate between multiple etcd clusters under the same domain. Works only with conjunction with srv. For example, if srv_suffix: foo and srv: example.org are set, the following DNS SRV query is made:_etcd-client-ssl-foo._tcp.example.com (and so on for every possible ETCD SRV service name).
• protocol: (optional) http or https, if not specified http is used. If the url or proxy is specified - will take protocol from them.
• username: (optional) username for etcd authentication.
• password: (optional) password for etcd authentication.
• cacert: (optional) The ca certificate. If present it will enable validation.
• cert: (optional) file with the client certificate.
• key: (optional) file with the client key. Can be empty if the key is part of cert.

Etcdv3

If you want that Patroni works with Etcd cluster via protocol version 3, you need to use the etcd3 section in the Patroni configuration file. All configuration parameters are the same as for etcd.

ZooKeeper

• hosts: List of ZooKeeper cluster members in format: $$'host1:port1', 'host2:port2', 'etc...'$$.
• use_ssl: (optional) Whether SSL is used or not. Defaults to false. If set to false, all SSL specific parameters are ignored.
• cacert: (optional) The CA certificate. If present it will enable validation.
• cert: (optional) File with the client certificate.
• key: (optional) File with the client key.
• key_password: (optional) The client key password.
• verify: (optional) Whether to verify certificate or not. Defaults to true.
• set_acls: (optional) If set, configures Kazoo to apply a default ACL to each ZNode that it creates. ACLs can use either the x509 schema (default) or other supported ZooKeeper schemes such as digest. They should be specified as a dictionary where the key is the full principal (optionally prefixed with the scheme) and the value is a list of permissions. Permissions may be one or more of CREATE, READ, WRITE, DELETE, ADMIN, or ALL. For example, set_acls: {CN=principal1: [CREATE, READ], digest:principal2:+pjROuBuuwNNSujKyH8dGcEnFPQ=: [ALL]}.
• auth_data: (optional) Authentication credentials to use for the connection. Should be a dictionary in the form that scheme is the key and credential is the value. Defaults to empty dictionary.

Exhibitor

• hosts: initial list of Exhibitor (ZooKeeper) nodes in format: ‘host1,host2,etc…’. This list updates automatically whenever the Exhibitor (ZooKeeper) cluster topology changes.
• poll_interval: how often the list of ZooKeeper and Exhibitor nodes should be updated from Exhibitor.
• port: Exhibitor port.

Kubernetes

• bypass_api_service: (optional) When communicating with the Kubernetes API, Patroni is usually relying on the kubernetes service, the address of which is exposed in the pods via the KUBERNETES_SERVICE_HOST environment variable. If bypass_api_service is set to true, Patroni will resolve the list of API nodes behind the service and connect directly to them.
• namespace: (optional) Kubernetes namespace where Patroni pod is running. Default value is default.
• labels: Labels in format {label1: value1, label2: value2}. These labels will be used to find existing objects (Pods and either Endpoints or ConfigMaps) associated with the current cluster. Also Patroni will set them on every object (Endpoint or ConfigMap) it creates.
• scope_label: (optional) name of the label containing cluster name. Default value is cluster-name.
• bootstrap_labels: (optional) Labels in format {label1: value1, label2: value2}. These labels will be assigned to a Patroni pod when its state is either initializing new cluster, running custom bootstrap script, starting after custom bootstrap or creating replica.
• role_label: (optional) name of the label containing role (primary, replica, or other custom value). Patroni will set this label on the pod it runs in. Default value is role.
• leader_label_value: (optional) value of the pod label when Postgres role is primary. Default value is primary.
• follower_label_value: (optional) value of the pod label when Postgres role is replica. Default value is replica.
• standby_leader_label_value: (optional) value of the pod label when Postgres role is standby_leader. Default value is primary.
• tmp_role_label: (optional) name of the temporary label containing role (primary or replica). Value of this label will always use the default of corresponding role. Set only when necessary.
• use_endpoints: (optional) if set to true, Patroni will use Endpoints instead of ConfigMaps to run leader elections and keep cluster state.
• pod_ip: (optional) IP address of the pod Patroni is running in. This value is required when use_endpoints is enabled and is used to populate the leader endpoint subsets when the pod’s PostgreSQL is promoted.
• ports: (optional) if the Service object has the name for the port, the same name must appear in the Endpoint object, otherwise service won’t work. For example, if your service is defined as {Kind: Service, spec: {ports: [{name: postgresql, port: 5432, targetPort: 5432}]}}, then you have to set kubernetes.ports: [{"name": "postgresql", "port": 5432}] and Patroni will use it for updating subsets of the leader Endpoint. This parameter is used only if kubernetes.use_endpoints is set.
• cacert: (optional) Specifies the file with the CA_BUNDLE file with certificates of trusted CAs to use while verifying Kubernetes API SSL certs. If not provided, patroni will use the value provided by the ServiceAccount secret.
• retriable_http_codes: (optional) list of HTTP status codes from K8s API to retry on. By default Patroni is retrying on 500, 503, and 504, or if K8s API response has retry-after HTTP header.

Raft (deprecated)

• self_addr: ip:port to listen on for Raft connections. The self_addr must be accessible from other nodes of the cluster. If not set, the node will not participate in consensus.

• bind_addr: (optional) ip:port to listen on for Raft connections. If not specified the self_addr will be used.

• partner_addrs: list of other Patroni nodes in the cluster in format:

  $$'ip1:port', 'ip2:port', 'etc...'$$

• data_dir: directory where to store Raft log and snapshot. If not specified the current working directory is used.

• password: (optional) Encrypt Raft traffic with a specified password, requires cryptography python module.

• min_timeout: (optional) minimum election timeout in seconds for the underlying pysyncobj Raft implementation. Must be greater than 3 * append_entries_period. Default: 0.4.

• max_timeout: (optional) maximum election timeout in seconds for the underlying pysyncobj Raft implementation. Must be greater than min_timeout. Default: 1.4.

• connection_timeout: (optional) time in seconds after which a connection with no data received is considered dead. Must be greater than or equal to max_timeout. Default: 3.5.

• append_entries_period: (optional) interval in seconds for sending heartbeat (append_entries) commands. Must be less than one-third of min_timeout. Default: 0.1.

• connection_retry_time: (optional) interval in seconds between reconnection attempts to offline nodes. Default: 5.0.

• leader_fallback_timeout: (optional) time in seconds after which a leader with no response from the majority falls back to follower state. Must be greater than append_entries_period. Default: 30.0.

Short FAQ about Raft implementation

• Q: How to list all the nodes providing consensus?

  A: syncobj_admin -conn host:port -status where the host:port is the address of one of the cluster nodes

• Q: Node that was a part of consensus and has gone and I can’t reuse the same IP for other node. How to remove this node from the consensus?

  A: syncobj_admin -conn host:port -remove host2:port2 where the host2:port2 is the address of the node you want to remove from consensus.

• Q: Where to get the syncobj_admin utility?

  A: It is installed together with pysyncobj module (python RAFT implementation), which is Patroni dependency.

• Q: it is possible to run Patroni node without adding in to the consensus?

  A: Yes, just comment out or remove raft.self_addr from Patroni configuration.

• Q: It is possible to run Patroni and PostgreSQL only on two nodes?

  A: Yes, on the third node you can run patroni_raft_controller (without Patroni and PostgreSQL). In such a setup, one can temporarily lose one node without affecting the primary.

PostgreSQL

• postgresql:

  • authentication:

    • superuser:
      • username: name for the superuser, set during initialization (initdb) and later used by Patroni to connect to the postgres.
      • password: password for the superuser, set during initialization (initdb).
      • sslmode: (optional) maps to the sslmode connection parameter, which allows a client to specify the type of TLS negotiation mode with the server. For more information on how each mode works, please visit the PostgreSQL documentation. The default mode is prefer.
      • sslkey: (optional) maps to the sslkey connection parameter, which specifies the location of the secret key used with the client’s certificate.
      • sslpassword: (optional) maps to the sslpassword connection parameter, which specifies the password for the secret key specified in sslkey.
      • sslcert: (optional) maps to the sslcert connection parameter, which specifies the location of the client certificate.
      • sslrootcert: (optional) maps to the sslrootcert connection parameter, which specifies the location of a file containing one or more certificate authorities (CA) certificates that the client will use to verify a server’s certificate.
      • sslcrl: (optional) maps to the sslcrl connection parameter, which specifies the location of a file containing a certificate revocation list. A client will reject connecting to any server that has a certificate present in this list.
      • sslcrldir: (optional) maps to the sslcrldir connection parameter, which specifies the location of a directory with files containing a certificate revocation list. A client will reject connecting to any server that has a certificate present in this list.
      • sslnegotiation: (optional) maps to the sslnegotiation connection parameter, which controls how SSL encryption is negotiated with the server, if SSL is used.
      • gssencmode: (optional) maps to the gssencmode connection parameter, which determines whether or with what priority a secure GSS TCP/IP connection will be negotiated with the server
      • channel_binding: (optional) maps to the channel_binding connection parameter, which controls the client’s use of channel binding.
    • replication:
      • username: replication username; the user will be created during initialization. Replicas will use this user to access the replication source via streaming replication
      • password: replication password; the user will be created during initialization.
      • sslmode: (optional) maps to the sslmode connection parameter, which allows a client to specify the type of TLS negotiation mode with the server. For more information on how each mode works, please visit the PostgreSQL documentation. The default mode is prefer.
      • sslkey: (optional) maps to the sslkey connection parameter, which specifies the location of the secret key used with the client’s certificate.
      • sslpassword: (optional) maps to the sslpassword connection parameter, which specifies the password for the secret key specified in sslkey.
      • sslcert: (optional) maps to the sslcert connection parameter, which specifies the location of the client certificate.
      • sslrootcert: (optional) maps to the sslrootcert connection parameter, which specifies the location of a file containing one or more certificate authorities (CA) certificates that the client will use to verify a server’s certificate.
      • sslcrl: (optional) maps to the sslcrl connection parameter, which specifies the location of a file containing a certificate revocation list. A client will reject connecting to any server that has a certificate present in this list.
      • sslcrldir: (optional) maps to the sslcrldir connection parameter, which specifies the location of a directory with files containing a certificate revocation list. A client will reject connecting to any server that has a certificate present in this list.
      • sslnegotiation: (optional) maps to the sslnegotiation connection parameter, which controls how SSL encryption is negotiated with the server, if SSL is used.
      • gssencmode: (optional) maps to the gssencmode connection parameter, which determines whether or with what priority a secure GSS TCP/IP connection will be negotiated with the server
      • channel_binding: (optional) maps to the channel_binding connection parameter, which controls the client’s use of channel binding.
    • rewind:
      • username: (optional) name for the user for pg_rewind; the user will be created during initialization of postgres 11+ and all necessary permissions will be granted.
      • password: (optional) password for the user for pg_rewind; the user will be created during initialization.
      • sslmode: (optional) maps to the sslmode connection parameter, which allows a client to specify the type of TLS negotiation mode with the server. For more information on how each mode works, please visit the PostgreSQL documentation. The default mode is prefer.
      • sslkey: (optional) maps to the sslkey connection parameter, which specifies the location of the secret key used with the client’s certificate.
      • sslpassword: (optional) maps to the sslpassword connection parameter, which specifies the password for the secret key specified in sslkey.
      • sslcert: (optional) maps to the sslcert connection parameter, which specifies the location of the client certificate.
      • sslrootcert: (optional) maps to the sslrootcert connection parameter, which specifies the location of a file containing one or more certificate authorities (CA) certificates that the client will use to verify a server’s certificate.
      • sslcrl: (optional) maps to the sslcrl connection parameter, which specifies the location of a file containing a certificate revocation list. A client will reject connecting to any server that has a certificate present in this list.
      • sslcrldir: (optional) maps to the sslcrldir connection parameter, which specifies the location of a directory with files containing a certificate revocation list. A client will reject connecting to any server that has a certificate present in this list.
      • sslnegotiation: (optional) maps to the sslnegotiation connection parameter, which controls how SSL encryption is negotiated with the server, if SSL is used.
      • gssencmode: (optional) maps to the gssencmode connection parameter, which determines whether or with what priority a secure GSS TCP/IP connection will be negotiated with the server
      • channel_binding: (optional) maps to the channel_binding connection parameter, which controls the client’s use of channel binding.

  • callbacks: callback scripts to run on certain actions. Patroni will pass the action, role and cluster name. (See scripts/aws.py as an example of how to write them.)

    • on_reload: run this script when configuration reload is triggered.
    • on_restart: run this script when the postgres restarts (without changing role).
    • on_role_change: run this script when the postgres is being promoted or demoted.
    • on_start: run this script when the postgres starts.
    • on_stop: run this script when the postgres stops.

  • connect_address: IP address + port through which Postgres is accessible from other nodes and applications.

  • proxy_address: IP address + port through which a connection pool (e.g. pgbouncer) running next to Postgres is accessible. The value is written to the member key in DCS as proxy_url and could be used/useful for service discovery.

  • create_replica_methods: an ordered list of the create methods for turning a Patroni node into a new replica. “basebackup” is the default method; other methods are assumed to refer to scripts, each of which is configured as its own config item. See custom replica creation methods documentation for further explanation.

  • data_dir: The location of the Postgres data directory, either existing or to be initialized by Patroni.

  • config_dir: The location of the Postgres configuration directory, defaults to the data directory. Must be writable by Patroni.

  • bin_dir: (optional) Path to PostgreSQL binaries (pg_ctl, initdb, pg_controldata, pg_basebackup, postgres, pg_isready, pg_rewind). If not provided or is an empty string, PATH environment variable will be used to find the executables.

  • bin_name: (optional) Make it possible to override Postgres binary names, if you are using a custom Postgres distribution:

    • pg_ctl: (optional) Custom name for pg_ctl binary.
    • initdb: (optional) Custom name for initdb binary.
    • pgcontroldata: (optional) Custom name for pg_controldata binary.
    • pg_basebackup: (optional) Custom name for pg_basebackup binary.
    • postgres: (optional) Custom name for postgres binary.
    • pg_isready: (optional) Custom name for pg_isready binary.
    • pg_rewind: (optional) Custom name for pg_rewind binary.

  • listen: IP address + port that Postgres listens to; must be accessible from other nodes in the cluster, if you’re using streaming replication. Multiple comma-separated addresses are permitted, as long as the port component is appended after to the last one with a colon, i.e. listen: 127.0.0.1,127.0.0.2:5432. Patroni will use the first address from this list to establish local connections to the PostgreSQL node.

  • use_unix_socket: specifies that Patroni should prefer to use unix sockets to connect to the cluster. Default value is false. If unix_socket_directories is defined, Patroni will use the first suitable value from it to connect to the cluster and fallback to tcp if nothing is suitable. If unix_socket_directories is not specified in postgresql.parameters, Patroni will assume that the default value should be used and omit host from the connection parameters.

  • use_unix_socket_repl: specifies that Patroni should prefer to use unix sockets for replication user cluster connection. Default value is false. If unix_socket_directories is defined, Patroni will use the first suitable value from it to connect to the cluster and fallback to tcp if nothing is suitable. If unix_socket_directories is not specified in postgresql.parameters, Patroni will assume that the default value should be used and omit host from the connection parameters.

  • pgpass: path to the .pgpass password file. Patroni creates this file before executing pg_basebackup, the post_init script and under some other circumstances. The location must be writable by Patroni.

  • recovery_conf: additional configuration settings written to recovery.conf when configuring follower.

  • custom_conf : path to an optional custom postgresql.conf file, that will be used in place of postgresql.base.conf. The file must exist on all cluster nodes, be readable by PostgreSQL and will be included from its location on the real postgresql.conf. Note that Patroni will not monitor this file for changes, nor backup it. However, its settings can still be overridden by Patroni’s own configuration facilities - see dynamic configuration for details.

  • parameters: configuration parameters (GUCs) for Postgres in format {ssl: "on", ssl_cert_file: "cert_file"}.

  • parameters_primary: (optional) role-specific parameter overrides for primary. These values are merged with and override the base parameters.

  • parameters_replica: (optional) role-specific parameter overrides for replica. These values are merged with and override the base parameters.

  • parameters_standby_leader: (optional) role-specific parameter overrides for standby_leader. These values are merged with and override the base parameters.

  • pg_hba: list of lines that Patroni will use to generate pg_hba.conf. Patroni ignores this parameter if hba_file PostgreSQL parameter is set to a non-default value. Together with dynamic configuration this parameter simplifies management of pg_hba.conf.

    • - host all all 0.0.0.0/0 md5
    • - host replication replicator 127.0.0.1/32 md5: A line like this is required for replication.

  • pg_hba_primary: (optional) role-specific pg_hba entries for primary. These completely replace pg_hba (no merging). If not defined, pg_hba is used.

  • pg_hba_replica: (optional) role-specific pg_hba entries for replica. These completely replace pg_hba (no merging). If not defined, pg_hba is used.

  • pg_hba_standby_leader: (optional) role-specific pg_hba entries for standby_leader. These completely replace pg_hba (no merging). If not defined, pg_hba is used.

  • pg_ident: list of lines that Patroni will use to generate pg_ident.conf. Patroni ignores this parameter if ident_file PostgreSQL parameter is set to a non-default value. Together with dynamic configuration this parameter simplifies management of pg_ident.conf.

    • - mapname1 systemname1 pguser1
    • - mapname1 systemname2 pguser2

  • pg_ident_primary: (optional) role-specific pg_ident entries for primary. These completely replace pg_ident (no merging). If not defined, pg_ident is used.

  • pg_ident_replica: (optional) role-specific pg_ident entries for replica. These completely replace pg_ident (no merging). If not defined, pg_ident is used.

  • pg_ident_standby_leader: (optional) role-specific pg_ident entries for standby_leader. These completely replace pg_ident (no merging). If not defined, pg_ident is used.

  • pg_ctl_timeout: How long should pg_ctl wait when doing start, stop or restart. Default value is 60 seconds.

  • use_pg_rewind: try to use pg_rewind on the former leader when it joins cluster as a replica. Either the cluster must be initialized with data page checksums (--data-checksums option for initdb) and/or wal_log_hints must be set to on, or pg_rewind will not work.

  • rewind: (optional) custom options to pass to the pg_rewind command. Can be specified as a list of strings and/or single key-value dictionaries. Not allowed options include: target-pgdata, source-pgdata, source-server, write-recovery-conf, dry-run, restore-target-wal, config-file, no-ensure-shutdown, version, and help. Example usage:

    YAML

    postgresql:
      rewind:
        - debug
        - progress
        - sync-method: fsync

  • remove_data_directory_on_rewind_failure: If this option is enabled, Patroni will remove the PostgreSQL data directory and recreate the replica. Otherwise it will try to follow the new leader. Default value is false.

  • remove_data_directory_on_diverged_timelines: Patroni will remove the PostgreSQL data directory and recreate the replica if it notices that timelines are diverging and the former primary can not start streaming from the new primary. This option is useful when pg_rewind can not be used. While performing timelines divergence check on PostgreSQL v10 and older Patroni will try to connect with replication credential to the “postgres” database. Hence, such access should be allowed in the pg_hba.conf. Default value is false.

  • replica_method: for each create_replica_methods other than basebackup, you would add a configuration section of the same name. At a minimum, this should include “command” with a full path to the actual script to be executed. Other configuration parameters will be passed along to the script in the form “parameter=value”.

  • pre_promote: a fencing script that executes during a failover after acquiring the leader lock but before promoting the replica. If the script exits with a non-zero code, Patroni does not promote the replica and removes the leader key from DCS.

  • before_stop: a script that executes immediately prior to stopping postgres. As opposed to a callback, this script runs synchronously, blocking shutdown until it has completed. The return code of this script does not impact whether shutdown proceeds afterwards.

REST API

• restapi:
  • thread_pool_size: size of thread pool used by Patroni to process REST API requests. Minimal value is 5, default value is 5.
  • connect_address: IP address (or hostname) and port, to access the Patroni’s REST API. All the members of the cluster must be able to connect to this address, so unless the Patroni setup is intended for a demo inside the localhost, this address must be a non “localhost” or loopback address (ie: “localhost” or “127.0.0.1”). It can serve as an endpoint for HTTP health checks (read below about the “listen” REST API parameter), and also for user queries (either directly or via the REST API), as well as for the health checks done by the cluster members during leader elections (for example, to determine whether the leader is still running, or if there is a node which has a WAL position that is ahead of the one doing the query; etc.) The connect_address is put in the member key in DCS, making it possible to translate the member name into the address to connect to its REST API.
  • listen: IP address (or hostname) and port that Patroni will listen to for the REST API - to provide also the same health checks and cluster messaging between the participating nodes, as described above. to provide health-check information for HAProxy (or any other load balancer capable of doing a HTTP “OPTION” or “GET” checks).
  • authentication: (optional)
    • username: Basic-auth username to protect unsafe REST API endpoints.
    • password: Basic-auth password to protect unsafe REST API endpoints.
  • certfile: (optional): Specifies the file with the certificate in the PEM format. If the certfile is not specified or is left empty, the API server will work without SSL.
  • keyfile: (optional): Specifies the file with the secret key in the PEM format.
  • keyfile_password: (optional): Specifies a password for decrypting the keyfile.
  • cafile: (optional): Specifies the file with the CA_BUNDLE with certificates of trusted CAs to use while verifying client certs.
  • ciphers: (optional): Specifies the permitted cipher suites (e.g. “ECDHE-RSA-AES256-GCM-SHA384:DHE-RSA-AES256-GCM-SHA384:ECDHE-RSA-AES128-GCM-SHA256:DHE-RSA-AES128-GCM-SHA256:!SSLv1:!SSLv2:!SSLv3:!TLSv1:!TLSv1.1”)
  • verify_client: (optional): none (default), optional or required. When none REST API will not check client certificates. When required client certificates are required for all REST API calls. When optional client certificates are required for all unsafe REST API endpoints. When required is used, then client authentication succeeds, if the certificate signature verification succeeds. For optional the client cert will only be checked for PUT, POST, PATCH, and DELETE requests.
  • allowlist: (optional): Specifies the set of hosts that are allowed to call unsafe REST API endpoints. The single element could be a host name, an IP address or a network address using CIDR notation. By default allow all is used. In case if allowlist or allowlist_include_members are set, anything that is not included is rejected.
  • allowlist_include_members: (optional): If set to true it allows accessing unsafe REST API endpoints from other cluster members registered in DCS (IP address or hostname is taken from the members api_url). Be careful, it might happen that OS will use a different IP for outgoing connections.
  • http_extra_headers: (optional): HTTP headers let the REST API server pass additional information with an HTTP response.
  • https_extra_headers: (optional): HTTPS headers let the REST API server pass additional information with an HTTP response when TLS is enabled. This will also pass additional information set in http_extra_headers.
  • request_queue_size: (optional): Sets request queue size for TCP socket used by Patroni REST API. Once the queue is full, further requests get a “Connection denied” error. The default value is 5.
  • server_tokens: (optional): Configures the value of the Server HTTP header.
    • Minimal: The header will contain only the Patroni version, e.g. Patroni/4.0.0.
    • ProductOnly: The header will contain only the product name, e.g. Patroni.
    • Original (default): The header will expose the original behaviour and display the BaseHTTP and Python versions, e.g. BaseHTTP/0.6 Python/3.12.3.

Here is an example of both http_extra_headers and https_extra_headers:

restapi:
  listen: <listen>
  connect_address: <connect_address>
  authentication:
    username: <username>
    password: <password>
  http_extra_headers:
    'X-Frame-Options': 'SAMEORIGIN'
    'X-XSS-Protection': '1; mode=block'
    'X-Content-Type-Options': 'nosniff'
  cafile: <ca file>
  certfile: <cert>
  keyfile: <key>
  https_extra_headers:
    'Strict-Transport-Security': 'max-age=31536000; includeSubDomains'

CTL

• ctl: (optional)
  • authentication:
    • username: Basic-auth username for accessing protected REST API endpoints. If not provided patronictl will use the value provided for REST API “username” parameter.
    • password: Basic-auth password for accessing protected REST API endpoints. If not provided patronictl will use the value provided for REST API “password” parameter.
  • insecure: Allow connections to REST API without verifying SSL certs.
  • cacert: Specifies the file with the CA_BUNDLE file or directory with certificates of trusted CAs to use while verifying REST API SSL certs. If not provided patronictl will use the value provided for REST API “cafile” parameter.
  • certfile: Specifies the file with the client certificate in the PEM format.
  • keyfile: Specifies the file with the client secret key in the PEM format.
  • keyfile_password: Specifies a password for decrypting the client keyfile.

Watchdog

• mode: off, automatic or required. When off watchdog is disabled. When automatic watchdog will be used if available, but ignored if it is not. When required the node will not become a leader unless watchdog can be successfully enabled.
• device: Path to watchdog device. Defaults to /dev/watchdog.
• safety_margin: Number of seconds of safety margin between watchdog triggering and leader key expiration.

Tags

• clonefrom: true or false. If set to true other nodes might prefer to use this node for bootstrap (take pg_basebackup from). If there are several nodes with clonefrom tag set to true the node to bootstrap from will be chosen randomly. The default value is false.
• noloadbalance: true or false. If set to true the node will return HTTP Status Code 503 for the GET /replica REST API health-check and therefore will be excluded from the load-balancing. Defaults to false.
• replicatefrom: The name of another replica to replicate from. Used to support cascading replication.
• nosync: true or false. If set to true the node will never be selected as a synchronous replica.
• sync_priority: integer, controls the priority this node should have during synchronous replica selection when synchronous_mode is set to on. Nodes with higher priority will be preferred over lower-priority nodes. If the sync_priority is 0 or negative - such node is not allowed to be written to synchronous_standby_names PostgreSQL parameter (similar to nosync: true). Keep in mind, that this parameter has the opposite meaning to sync_priority value reported in pg_stat_replication view.
• nofailover: true or false, controls whether this node is allowed to participate in the leader race and become a leader. Defaults to false, meaning this node can_ participate in leader races.
• failover_priority: integer, controls the priority this node should have during failover. Nodes with higher priority will be preferred over lower-priority nodes if they received/replayed the same amount of WAL. However, nodes with higher values of receive/replay LSN are preferred regardless of their priority. If the failover_priority is 0 or negative - such node is not allowed to participate in the leader race and to become a leader (similar to nofailover: true). Known limitation: failover_priority currently doesn’t work with quorum-based synchronous replication.
• nostream: true or false. If set to true the node will not use replication protocol to stream WAL. It will rely instead on archive recovery (if restore_command is configured) and pg_wal/pg_xlog polling. It also disables copying and synchronization of permanent logical replication slots on the node itself and all its cascading replicas. Setting this tag on primary node has no effect.

In addition to these predefined tags, you can also add your own ones:

• key1: true
• key2: false
• key3: 1.4
• key4: "RandomString"

Tags are visible in the REST API and patronictl_list You can also check for an instance health using these tags. If the tag isn’t defined for an instance, or if the respective value doesn’t match the querying value, it will return HTTP Status Code 503.

3.3 - Environment Configuration Settings

Source: https://patroni.readthedocs.io/en/latest/ENVIRONMENT.html

It is possible to override some of the configuration parameters defined in the Patroni configuration file using the system environment variables. This document lists all environment variables handled by Patroni. The values set via those variables always take precedence over the ones set in the Patroni configuration file.

Global/Universal

• PATRONI_CONFIGURATION: it is possible to set the entire configuration for the Patroni via PATRONI_CONFIGURATION environment variable. In this case any other environment variables will not be considered!
• PATRONI_THREAD_POOL_SIZE: size of thread pool used by Patroni to execute asynchronous tasks and communicate via REST API with other members during leader race or failsafe checks. Minimal value is 5, default value is 5.
• PATRONI_THREAD_STACK_SIZE: specifies the stack size to be used for threads started by Patroni. Value must be aligned by 64kB. Minimal value is 64kB, default value (set by Patroni) is 512kB.
• PATRONI_NAME: name of the node where the current instance of Patroni is running. Must be unique for the cluster. The value __patroni_strict_sync_replica_placeholder__ is reserved for internal use by Patroni and cannot be used as a node name.
• PATRONI_NAMESPACE: path within the configuration store where Patroni will keep information about the cluster. Default value: “/service”
• PATRONI_SCOPE: cluster name
• PG_MALLOC_ARENA_MAX: custom value for MALLOC_ARENA_MAX environment variable for postmaster process. If not set, postmaster will inherit MALLOC_ARENA_MAX value.

Log

• PATRONI_LOG_TYPE: sets the format of logs. Can be either plain or json. To use json format, you must have the jsonlogger installed. The default value is plain.
• PATRONI_LOG_LEVEL: sets the general logging level. Default value is INFO (see the docs for Python logging)
• PATRONI_LOG_TRACEBACK_LEVEL: sets the level where tracebacks will be visible. Default value is ERROR. Set it to DEBUG if you want to see tracebacks only if you enable PATRONI_LOG_LEVEL=DEBUG.
• PATRONI_LOG_FORMAT: sets the log formatting string. If the log type is plain, the log format should be a string. Refer to the LogRecord attributes for available attributes. If the log type is json, the log format can be a list in addition to a string. Each list item should correspond to LogRecord attributes. Be cautious that only the field name is required, and the %( and ) should be omitted. If you wish to print a log field with a different key name, use a dictionary where the dictionary key is the log field, and the value is the name of the field you want to be printed in the log. Default value is %(asctime)s %(levelname)s: %(message)s
• PATRONI_LOG_DATEFORMAT: sets the datetime formatting string. (see the formatTime() documentation)
• PATRONI_LOG_STATIC_FIELDS: add additional fields to the log. This option is only available when the log type is set to json. Example PATRONI_LOG_STATIC_FIELDS="{app: patroni}"
• PATRONI_LOG_MAX_QUEUE_SIZE: Patroni is using two-step logging. Log records are written into the in-memory queue and there is a separate thread which pulls them from the queue and writes to stderr or file. The maximum size of the internal queue is limited by default by 1000 records, which is enough to keep logs for the past 1h20m.
• PATRONI_LOG_DIR: Directory to write application logs to. The directory must exist and be writable by the user executing Patroni. If you set this env variable, the application will retain 4 25MB logs by default. You can tune those retention values with PATRONI_LOG_FILE_NUM and PATRONI_LOG_FILE_SIZE (see below).
• PATRONI_LOG_MODE: Permissions for log files (for example, 0644). If not specified, permissions will be set based on the current umask value.
• PATRONI_LOG_FILE_NUM: The number of application logs to retain.
• PATRONI_LOG_FILE_SIZE: Size of patroni.log file (in bytes) that triggers a log rolling.
• PATRONI_LOG_LOGGERS: Redefine logging level per python module. Example PATRONI_LOG_LOGGERS="{patroni.postmaster: WARNING, urllib3: DEBUG}"
• PATRONI_LOG_DEDUPLICATE_HEARTBEAT_LOGS: If set to true, successive heartbeat logs that are identical shall not be output. Default value is false.

Citus

Enables integration Patroni with Citus. If configured, Patroni will take care of registering Citus worker nodes on the coordinator. You can find more information about Citus support here.

• PATRONI_CITUS_GROUP: the Citus group id, integer. Use 0 for coordinator and 1, 2, etc… for workers
• PATRONI_CITUS_DATABASE: the database where citus extension should be created. Must be the same on the coordinator and all workers. Currently only one database is supported.

Consul

• PATRONI_CONSUL_HOST: the host:port for the Consul local agent.
• PATRONI_CONSUL_URL: url for the Consul local agent, in format: http(s)://host:port
• PATRONI_CONSUL_PORT: (optional) Consul port
• PATRONI_CONSUL_SCHEME: (optional) http or https, defaults to http
• PATRONI_CONSUL_TOKEN: (optional) ACL token
• PATRONI_CONSUL_VERIFY: (optional) whether to verify the SSL certificate for HTTPS requests
• PATRONI_CONSUL_CACERT: (optional) The ca certificate. If present it will enable validation.
• PATRONI_CONSUL_CERT: (optional) File with the client certificate
• PATRONI_CONSUL_KEY: (optional) File with the client key. Can be empty if the key is part of certificate.
• PATRONI_CONSUL_DC: (optional) Datacenter to communicate with. By default the datacenter of the host is used.
• PATRONI_CONSUL_CONSISTENCY: (optional) Select consul consistency mode. Possible values are default, consistent, or stale (more details in consul API reference)
• PATRONI_CONSUL_CHECKS: (optional) list of Consul health checks used for the session. By default an empty list is used.
• PATRONI_CONSUL_REGISTER_SERVICE: (optional) whether or not to register a service with the name defined by the scope parameter and the tag master, primary, replica, or standby-leader depending on the node’s role. Defaults to false
• PATRONI_CONSUL_SERVICE_TAGS: (optional) additional static tags to add to the Consul service apart from the role (primary/replica/standby-leader). By default an empty list is used.
• PATRONI_CONSUL_SERVICE_CHECK_INTERVAL: (optional) how often to perform health check against registered url
• PATRONI_CONSUL_SERVICE_CHECK_TLS_SERVER_NAME: (optional) override SNI host when connecting via TLS, see also consul agent check API reference.

Etcd

• PATRONI_ETCD_PROXY: proxy url for the etcd. If you are connecting to the etcd using proxy, use this parameter instead of PATRONI_ETCD_URL
• PATRONI_ETCD_URL: url for the etcd, in format: http(s)://(username:password@)host:port
• PATRONI_ETCD_HOSTS: list of etcd endpoints in format ‘host1:port1’,‘host2:port2’,etc…
• PATRONI_ETCD_USE_PROXIES: If this parameter is set to true, Patroni will consider hosts as a list of proxies and will not perform a topology discovery of etcd cluster but stick to a fixed list of hosts.
• PATRONI_ETCD_PROTOCOL: http or https, if not specified http is used. If the url or proxy is specified - will take protocol from them.
• PATRONI_ETCD_HOST: the host:port for the etcd endpoint.
• PATRONI_ETCD_SRV: Domain to search the SRV record(s) for cluster autodiscovery. Patroni will try to query these SRV service names for specified domain (in that order until first success): _etcd-client-ssl, _etcd-client, _etcd-ssl, _etcd, _etcd-server-ssl, _etcd-server. If SRV records for _etcd-server-ssl or _etcd-server are retrieved then ETCD peer protocol is used do query ETCD for available members. Otherwise hosts from SRV records will be used.
• PATRONI_ETCD_SRV_SUFFIX: Configures a suffix to the SRV name that is queried during discovery. Use this flag to differentiate between multiple etcd clusters under the same domain. Works only with conjunction with PATRONI_ETCD_SRV. For example, if PATRONI_ETCD_SRV_SUFFIX=foo and PATRONI_ETCD_SRV=example.org are set, the following DNS SRV query is made:_etcd-client-ssl-foo._tcp.example.com (and so on for every possible ETCD SRV service name).
• PATRONI_ETCD_USERNAME: username for etcd authentication.
• PATRONI_ETCD_PASSWORD: password for etcd authentication.
• PATRONI_ETCD_CACERT: The ca certificate. If present it will enable validation.
• PATRONI_ETCD_CERT: File with the client certificate.
• PATRONI_ETCD_KEY: File with the client key. Can be empty if the key is part of certificate.

Etcdv3

Environment names for Etcdv3 are similar as for Etcd, you just need to use ETCD3 instead of ETCD in the variable name. Example: PATRONI_ETCD3_HOST, PATRONI_ETCD3_CACERT, and so on.

ZooKeeper

• PATRONI_ZOOKEEPER_HOSTS: Comma separated list of ZooKeeper cluster members: “‘host1:port1’,‘host2:port2’,’etc…’”. It is important to quote every single entity!
• PATRONI_ZOOKEEPER_USE_SSL: (optional) Whether SSL is used or not. Defaults to false. If set to false, all SSL specific parameters are ignored.
• PATRONI_ZOOKEEPER_CACERT: (optional) The CA certificate. If present it will enable validation.
• PATRONI_ZOOKEEPER_CERT: (optional) File with the client certificate.
• PATRONI_ZOOKEEPER_KEY: (optional) File with the client key.
• PATRONI_ZOOKEEPER_KEY_PASSWORD: (optional) The client key password.
• PATRONI_ZOOKEEPER_VERIFY: (optional) Whether to verify certificate or not. Defaults to true.
• PATRONI_ZOOKEEPER_SET_ACLS: (optional) If set, configures Kazoo to apply a default ACL to each ZNode that it creates. ACLs can use either the x509 schema (default) or other supported ZooKeeper schemes such as digest. They should be specified as a dictionary where the key is the full principal (optionally prefixed with the scheme) and the value is a list of permissions. Permissions may be one or more of CREATE, READ, WRITE, DELETE, ADMIN, or ALL. For example, set_acls: {CN=principal1: [CREATE, READ], digest:principal2:+pjROuBuuwNNSujKyH8dGcEnFPQ=: [ALL]}.
• PATRONI_ZOOKEEPER_AUTH_DATA: (optional) Authentication credentials to use for the connection. Should be a dictionary in the form that scheme is the key and credential is the value. Defaults to empty dictionary.

Exhibitor

• PATRONI_EXHIBITOR_HOSTS: initial list of Exhibitor (ZooKeeper) nodes in format: ‘host1,host2,etc…’. This list updates automatically whenever the Exhibitor (ZooKeeper) cluster topology changes.
• PATRONI_EXHIBITOR_PORT: Exhibitor port.

Kubernetes

• PATRONI_KUBERNETES_BYPASS_API_SERVICE: (optional) When communicating with the Kubernetes API, Patroni is usually relying on the kubernetes service, the address of which is exposed in the pods via the KUBERNETES_SERVICE_HOST environment variable. If PATRONI_KUBERNETES_BYPASS_API_SERVICE is set to true, Patroni will resolve the list of API nodes behind the service and connect directly to them.
• PATRONI_KUBERNETES_NAMESPACE: (optional) Kubernetes namespace where the Patroni pod is running. Default value is default.
• PATRONI_KUBERNETES_LABELS: Labels in format {label1: value1, label2: value2}. These labels will be used to find existing objects (Pods and either Endpoints or ConfigMaps) associated with the current cluster. Also Patroni will set them on every object (Endpoint or ConfigMap) it creates.
• PATRONI_KUBERNETES_SCOPE_LABEL: (optional) name of the label containing cluster name. Default value is cluster-name.
• PATRONI_KUBERNETES_BOOTSTRAP_LABELS: (optional) Labels in format {label1: value1, label2: value2}. These labels will be assigned to a Patroni pod when its state is either initializing new cluster, running custom bootstrap script, starting after custom bootstrap or creating replica.
• PATRONI_KUBERNETES_ROLE_LABEL: (optional) name of the label containing role (primary, replica or other custom value). Patroni will set this label on the pod it runs in. Default value is role.
• PATRONI_KUBERNETES_LEADER_LABEL_VALUE: (optional) value of the pod label when Postgres role is primary. Default value is primary.
• PATRONI_KUBERNETES_FOLLOWER_LABEL_VALUE: (optional) value of the pod label when Postgres role is replica. Default value is replica.
• PATRONI_KUBERNETES_STANDBY_LEADER_LABEL_VALUE: (optional) value of the pod label when Postgres role is standby_leader. Default value is primary.
• PATRONI_KUBERNETES_TMP_ROLE_LABEL: (optional) name of the temporary label containing role (primary or replica). Value of this label will always use the default of corresponding role. Set only when necessary.
• PATRONI_KUBERNETES_USE_ENDPOINTS: (optional) if set to true, Patroni will use Endpoints instead of ConfigMaps to run leader elections and keep cluster state.
• PATRONI_KUBERNETES_POD_IP: (optional) IP address of the pod Patroni is running in. This value is required when PATRONI_KUBERNETES_USE_ENDPOINTS is enabled and is used to populate the leader endpoint subsets when the pod’s PostgreSQL is promoted.
• PATRONI_KUBERNETES_PORTS: (optional) if the Service object has the name for the port, the same name must appear in the Endpoint object, otherwise service won’t work. For example, if your service is defined as {Kind: Service, spec: {ports: [{name: postgresql, port: 5432, targetPort: 5432}]}}, then you have to set PATRONI_KUBERNETES_PORTS='[{"name": "postgresql", "port": 5432}]' and Patroni will use it for updating subsets of the leader Endpoint. This parameter is used only if PATRONI_KUBERNETES_USE_ENDPOINTS is set.
• PATRONI_KUBERNETES_CACERT: (optional) Specifies the file with the CA_BUNDLE file with certificates of trusted CAs to use while verifying Kubernetes API SSL certs. If not provided, patroni will use the value provided by the ServiceAccount secret.
• PATRONI_RETRIABLE_HTTP_CODES: (optional) list of HTTP status codes from K8s API to retry on. By default Patroni is retrying on 500, 503, and 504, or if K8s API response has retry-after HTTP header.

Raft (deprecated)

• PATRONI_RAFT_SELF_ADDR: ip:port to listen on for Raft connections. The self_addr must be accessible from other nodes of the cluster. If not set, the node will not participate in consensus.
• PATRONI_RAFT_BIND_ADDR: (optional) ip:port to listen on for Raft connections. If not specified the self_addr will be used.
• PATRONI_RAFT_PARTNER_ADDRS: list of other Patroni nodes in the cluster in format "'ip1:port1','ip2:port2'". It is important to quote every single entity!
• PATRONI_RAFT_DATA_DIR: directory where to store Raft log and snapshot. If not specified the current working directory is used.
• PATRONI_RAFT_PASSWORD: (optional) Encrypt Raft traffic with a specified password, requires cryptography python module.
• PATRONI_RAFT_MIN_TIMEOUT: (optional) minimum election timeout in seconds for the underlying pysyncobj Raft implementation. Must be greater than 3 * PATRONI_RAFT_APPEND_ENTRIES_PERIOD. Default: 0.4.
• PATRONI_RAFT_MAX_TIMEOUT: (optional) maximum election timeout in seconds for the underlying pysyncobj Raft implementation. Must be greater than PATRONI_RAFT_MIN_TIMEOUT. Default: 1.4.
• PATRONI_RAFT_CONNECTION_TIMEOUT: (optional) time in seconds after which a connection with no data received is considered dead. Must be greater than or equal to PATRONI_RAFT_MAX_TIMEOUT. Default: 3.5.
• PATRONI_RAFT_APPEND_ENTRIES_PERIOD: (optional) interval in seconds for sending heartbeat commands. Must be less than one-third of PATRONI_RAFT_MIN_TIMEOUT. Default: 0.1.
• PATRONI_RAFT_CONNECTION_RETRY_TIME: (optional) interval in seconds between reconnection attempts to offline nodes. Default: 5.0.
• PATRONI_RAFT_LEADER_FALLBACK_TIMEOUT: (optional) time in seconds after which a leader with no response from the majority falls back to follower state. Must be greater than PATRONI_RAFT_APPEND_ENTRIES_PERIOD. Default: 30.0.

PostgreSQL

• PATRONI_POSTGRESQL_LISTEN: IP address + port that Postgres listens to. Multiple comma-separated addresses are permitted, as long as the port component is appended after to the last one with a colon, i.e. listen: 127.0.0.1,127.0.0.2:5432. Patroni will use the first address from this list to establish local connections to the PostgreSQL node.
• PATRONI_POSTGRESQL_CONNECT_ADDRESS: IP address + port through which Postgres is accessible from other nodes and applications.
• PATRONI_POSTGRESQL_PROXY_ADDRESS: IP address + port through which a connection pool (e.g. pgbouncer) running next to Postgres is accessible. The value is written to the member key in DCS as proxy_url and could be used/useful for service discovery.
• PATRONI_POSTGRESQL_DATA_DIR: The location of the Postgres data directory, either existing or to be initialized by Patroni.
• PATRONI_POSTGRESQL_CONFIG_DIR: The location of the Postgres configuration directory, defaults to the data directory. Must be writable by Patroni.
• PATRONI_POSTGRESQL_BIN_DIR: Path to PostgreSQL binaries. (pg_ctl, initdb, pg_controldata, pg_basebackup, postgres, pg_isready, pg_rewind) The default value is an empty string meaning that PATH environment variable will be used to find the executables.
• PATRONI_POSTGRESQL_BIN_PG_CTL: (optional) Custom name for pg_ctl binary.
• PATRONI_POSTGRESQL_BIN_INITDB: (optional) Custom name for initdb binary.
• PATRONI_POSTGRESQL_BIN_PG_CONTROLDATA: (optional) Custom name for pg_controldata binary.
• PATRONI_POSTGRESQL_BIN_PG_BASEBACKUP: (optional) Custom name for pg_basebackup binary.
• PATRONI_POSTGRESQL_BIN_POSTGRES: (optional) Custom name for postgres binary.
• PATRONI_POSTGRESQL_BIN_IS_READY: (optional) Custom name for pg_isready binary.
• PATRONI_POSTGRESQL_BIN_PG_REWIND: (optional) Custom name for pg_rewind binary.
• PATRONI_POSTGRESQL_PGPASS: path to the .pgpass password file. Patroni creates this file before executing pg_basebackup and under some other circumstances. The location must be writable by Patroni.
• PATRONI_REPLICATION_USERNAME: replication username; the user will be created during initialization. Replicas will use this user to access the replication source via streaming replication
• PATRONI_REPLICATION_PASSWORD: replication password; the user will be created during initialization.
• PATRONI_REPLICATION_SSLMODE: (optional) maps to the sslmode connection parameter, which allows a client to specify the type of TLS negotiation mode with the server. For more information on how each mode works, please visit the PostgreSQL documentation. The default mode is prefer.
• PATRONI_REPLICATION_SSLKEY: (optional) maps to the sslkey connection parameter, which specifies the location of the secret key used with the client’s certificate.
• PATRONI_REPLICATION_SSLPASSWORD: (optional) maps to the sslpassword connection parameter, which specifies the password for the secret key specified in PATRONI_REPLICATION_SSLKEY.
• PATRONI_REPLICATION_SSLCERT: (optional) maps to the sslcert connection parameter, which specifies the location of the client certificate.
• PATRONI_REPLICATION_SSLROOTCERT: (optional) maps to the sslrootcert connection parameter, which specifies the location of a file containing one or more certificate authorities (CA) certificates that the client will use to verify a server’s certificate.
• PATRONI_REPLICATION_SSLCRL: (optional) maps to the sslcrl connection parameter, which specifies the location of a file containing a certificate revocation list. A client will reject connecting to any server that has a certificate present in this list.
• PATRONI_REPLICATION_SSLCRLDIR: (optional) maps to the sslcrldir connection parameter, which specifies the location of a directory with files containing a certificate revocation list. A client will reject connecting to any server that has a certificate present in this list.
• PATRONI_REPLICATION_SSLNEGOTIATION: (optional) maps to the sslnegotiation connection parameter, which controls how SSL encryption is negotiated with the server, if SSL is used.
• PATRONI_REPLICATION_GSSENCMODE: (optional) maps to the gssencmode connection parameter, which determines whether or with what priority a secure GSS TCP/IP connection will be negotiated with the server
• PATRONI_REPLICATION_CHANNEL_BINDING: (optional) maps to the channel_binding connection parameter, which controls the client’s use of channel binding.
• PATRONI_SUPERUSER_USERNAME: name for the superuser, set during initialization (initdb) and later used by Patroni to connect to the postgres. Also this user is used by pg_rewind.
• PATRONI_SUPERUSER_PASSWORD: password for the superuser, set during initialization (initdb).
• PATRONI_SUPERUSER_SSLMODE: (optional) maps to the sslmode connection parameter, which allows a client to specify the type of TLS negotiation mode with the server. For more information on how each mode works, please visit the PostgreSQL documentation. The default mode is prefer.
• PATRONI_SUPERUSER_SSLKEY: (optional) maps to the sslkey connection parameter, which specifies the location of the secret key used with the client’s certificate.
• PATRONI_SUPERUSER_SSLPASSWORD: (optional) maps to the sslpassword connection parameter, which specifies the password for the secret key specified in PATRONI_SUPERUSER_SSLKEY.
• PATRONI_SUPERUSER_SSLCERT: (optional) maps to the sslcert connection parameter, which specifies the location of the client certificate.
• PATRONI_SUPERUSER_SSLROOTCERT: (optional) maps to the sslrootcert connection parameter, which specifies the location of a file containing one or more certificate authorities (CA) certificates that the client will use to verify a server’s certificate.
• PATRONI_SUPERUSER_SSLCRL: (optional) maps to the sslcrl connection parameter, which specifies the location of a file containing a certificate revocation list. A client will reject connecting to any server that has a certificate present in this list.
• PATRONI_SUPERUSER_SSLCRLDIR: (optional) maps to the sslcrldir connection parameter, which specifies the location of a directory with files containing a certificate revocation list. A client will reject connecting to any server that has a certificate present in this list.
• PATRONI_SUPERUSER_SSLNEGOTIATION: (optional) maps to the sslnegotiation connection parameter, which controls how SSL encryption is negotiated with the server, if SSL is used.
• PATRONI_SUPERUSER_GSSENCMODE: (optional) maps to the gssencmode connection parameter, which determines whether or with what priority a secure GSS TCP/IP connection will be negotiated with the server
• PATRONI_SUPERUSER_CHANNEL_BINDING: (optional) maps to the channel_binding connection parameter, which controls the client’s use of channel binding.
• PATRONI_REWIND_USERNAME: (optional) name for the user for pg_rewind; the user will be created during initialization of postgres 11+ and all necessary permissions will be granted.
• PATRONI_REWIND_PASSWORD: (optional) password for the user for pg_rewind; the user will be created during initialization.
• PATRONI_REWIND_SSLMODE: (optional) maps to the sslmode connection parameter, which allows a client to specify the type of TLS negotiation mode with the server. For more information on how each mode works, please visit the PostgreSQL documentation. The default mode is prefer.
• PATRONI_REWIND_SSLKEY: (optional) maps to the sslkey connection parameter, which specifies the location of the secret key used with the client’s certificate.
• PATRONI_REWIND_SSLPASSWORD: (optional) maps to the sslpassword connection parameter, which specifies the password for the secret key specified in PATRONI_REWIND_SSLKEY.
• PATRONI_REWIND_SSLCERT: (optional) maps to the sslcert connection parameter, which specifies the location of the client certificate.
• PATRONI_REWIND_SSLROOTCERT: (optional) maps to the sslrootcert connection parameter, which specifies the location of a file containing one or more certificate authorities (CA) certificates that the client will use to verify a server’s certificate.
• PATRONI_REWIND_SSLCRL: (optional) maps to the sslcrl connection parameter, which specifies the location of a file containing a certificate revocation list. A client will reject connecting to any server that has a certificate present in this list.
• PATRONI_REWIND_SSLCRLDIR: (optional) maps to the sslcrldir connection parameter, which specifies the location of a directory with files containing a certificate revocation list. A client will reject connecting to any server that has a certificate present in this list.
• PATRONI_REWIND_SSLNEGOTIATION: (optional) maps to the sslnegotiation connection parameter, which controls how SSL encryption is negotiated with the server, if SSL is used.
• PATRONI_REWIND_GSSENCMODE: (optional) maps to the gssencmode connection parameter, which determines whether or with what priority a secure GSS TCP/IP connection will be negotiated with the server
• PATRONI_REWIND_CHANNEL_BINDING: (optional) maps to the channel_binding connection parameter, which controls the client’s use of channel binding.

REST API

• PATRONI_RESTAPI_THREAD_POOL_SIZE: size of thread pool used by Patroni to process REST API requests. Minimal value is 5, default value is 5.
• PATRONI_RESTAPI_CONNECT_ADDRESS: IP address and port to access the REST API.
• PATRONI_RESTAPI_LISTEN: IP address and port that Patroni will listen to, to provide health-check information for HAProxy.
• PATRONI_RESTAPI_USERNAME: Basic-auth username to protect unsafe REST API endpoints.
• PATRONI_RESTAPI_PASSWORD: Basic-auth password to protect unsafe REST API endpoints.
• PATRONI_RESTAPI_CERTFILE: Specifies the file with the certificate in the PEM format. If the certfile is not specified or is left empty, the API server will work without SSL.
• PATRONI_RESTAPI_KEYFILE: Specifies the file with the secret key in the PEM format.
• PATRONI_RESTAPI_KEYFILE_PASSWORD: Specifies a password for decrypting the keyfile.
• PATRONI_RESTAPI_CAFILE: Specifies the file with the CA_BUNDLE with certificates of trusted CAs to use while verifying client certs.
• PATRONI_RESTAPI_CIPHERS: (optional) Specifies the permitted cipher suites (e.g. “ECDHE-RSA-AES256-GCM-SHA384:DHE-RSA-AES256-GCM-SHA384:ECDHE-RSA-AES128-GCM-SHA256:DHE-RSA-AES128-GCM-SHA256:!SSLv1:!SSLv2:!SSLv3:!TLSv1:!TLSv1.1”)
• PATRONI_RESTAPI_VERIFY_CLIENT: none (default), optional or required. When none REST API will not check client certificates. When required client certificates are required for all REST API calls. When optional client certificates are required for all unsafe REST API endpoints. When required is used, then client authentication succeeds, if the certificate signature verification succeeds. For optional the client cert will only be checked for PUT, POST, PATCH, and DELETE requests.
• PATRONI_RESTAPI_ALLOWLIST: (optional): Specifies the set of hosts that are allowed to call unsafe REST API endpoints. The single element could be a host name, an IP address or a network address using CIDR notation. By default allow all is used. In case if allowlist or allowlist_include_members are set, anything that is not included is rejected.
• PATRONI_RESTAPI_ALLOWLIST_INCLUDE_MEMBERS: (optional): If set to true it allows accessing unsafe REST API endpoints from other cluster members registered in DCS (IP address or hostname is taken from the members api_url). Be careful, it might happen that OS will use a different IP for outgoing connections.
• PATRONI_RESTAPI_HTTP_EXTRA_HEADERS: (optional) HTTP headers let the REST API server pass additional information with an HTTP response.
• PATRONI_RESTAPI_HTTPS_EXTRA_HEADERS: (optional) HTTPS headers let the REST API server pass additional information with an HTTP response when TLS is enabled. This will also pass additional information set in http_extra_headers.
• PATRONI_RESTAPI_REQUEST_QUEUE_SIZE: (optional): Sets request queue size for TCP socket used by Patroni REST API. Once the queue is full, further requests get a “Connection denied” error. The default value is 5.
• PATRONI_RESTAPI_SERVER_TOKENS: (optional) Configures the value of the Server HTTP header. Original (default) will expose the original behaviour and display the BaseHTTP and Python versions, e.g. BaseHTTP/0.6 Python/3.12.3. Minimal: The header will contain only the Patroni version, e.g. Patroni/4.0.0. ProductOnly: The header will contain only the product name, e.g. Patroni.

CTL

• PATRONICTL_CONFIG_FILE: (optional) location of the configuration file.
• PATRONI_CTL_USERNAME: (optional) Basic-auth username for accessing protected REST API endpoints. If not provided patronictl will use the value provided for REST API “username” parameter.
• PATRONI_CTL_PASSWORD: (optional) Basic-auth password for accessing protected REST API endpoints. If not provided patronictl will use the value provided for REST API “password” parameter.
• PATRONI_CTL_INSECURE: (optional) Allow connections to REST API without verifying SSL certs.
• PATRONI_CTL_CACERT: (optional) Specifies the file with the CA_BUNDLE file or directory with certificates of trusted CAs to use while verifying REST API SSL certs. If not provided patronictl will use the value provided for REST API “cafile” parameter.
• PATRONI_CTL_CERTFILE: (optional) Specifies the file with the client certificate in the PEM format.
• PATRONI_CTL_KEYFILE: (optional) Specifies the file with the client secret key in the PEM format.
• PATRONI_CTL_KEYFILE_PASSWORD: (optional) Specifies a password for decrypting the client keyfile.

4 - Patroni REST API

Source: https://patroni.readthedocs.io/en/latest/rest_api.html

Patroni has a rich REST API, which is used by Patroni itself during the leader race, by the patronictl tool in order to perform failovers/switchovers/reinitialize/restarts/reloads, by HAProxy or any other kind of load balancer to perform HTTP health checks, and of course could also be used for monitoring. Below you will find the list of Patroni REST API endpoints.

Health check endpoints

For all health check GET requests Patroni returns a JSON document with the status of the node, along with the HTTP status code. If you don’t want or don’t need the JSON document, you might consider using the HEAD or OPTIONS method instead of GET.

• The following requests to Patroni REST API will return HTTP status code 200 only when the Patroni node is running as the primary with leader lock:

  • GET /
  • GET /primary
  • GET /read-write

• GET /standby-leader: returns HTTP status code 200 only when the Patroni node is running as the leader in a standby cluster.

• GET /leader: returns HTTP status code 200 when the Patroni node has the leader lock. The major difference from the two previous endpoints is that it doesn’t take into account whether PostgreSQL is running as the primary or the standby_leader.

• GET /replica: replica health check endpoint. It returns HTTP status code 200 only when the Patroni node is in the state running, the role is replica and noloadbalance tag is not set.

• GET /replica?replication_state=<required state>: replica check endpoint. In addition to checks from replica, it also checks if the replication state matches the required one. Mainly useful with replication_state=streaming, to exclude replicas still catching up in archive recovery.

• GET /replica?lag=<max-lag>: replica check endpoint. In addition to checks from replica, it also checks replication latency and returns status code 200 only when it is below specified value. The key cluster.last_leader_operation from DCS is used for Leader wal position and compute latency on replica for performance reasons. max-lag can be specified in bytes (integer) or in human readable values, for e.g. 16kB, 64MB, 1GB.

  • GET /replica?lag=1048576
  • GET /replica?lag=1024kB
  • GET /replica?lag=10MB
  • GET /replica?lag=1GB

• GET /replica?tag_key1=value1&tag_key2=value2: replica check endpoint. In addition, It will also check for user defined tags key1 and key2 and their respective values in the tags section of the yaml configuration management. If the tag isn’t defined for an instance, or if the value in the yaml configuration doesn’t match the querying value, it will return HTTP Status Code 503.

  In the following requests, since we are checking for the leader or standby-leader status, Patroni doesn’t apply any of the user defined tags and they will be ignored.

  • GET /?tag_key1=value1&tag_key2=value2
  • GET /leader?tag_key1=value1&tag_key2=value2
  • GET /primary?tag_key1=value1&tag_key2=value2
  • GET /read-write?tag_key1=value1&tag_key2=value2
  • GET /standby_leader?tag_key1=value1&tag_key2=value2
  • GET /standby-leader?tag_key1=value1&tag_key2=value2

• GET /read-only: like the above endpoint, but also includes the primary.

• GET /synchronous or GET /sync: returns HTTP status code 200 only when the Patroni node is running as a synchronous standby.

• GET /read-only-sync: like the above endpoint, but also includes the primary.

• GET /quorum: returns HTTP status code 200 only when this Patroni node is listed as a quorum node in synchronous_standby_names on the primary.

• GET /read-only-quorum: like the above endpoint, but also includes the primary.

• GET /asynchronous or GET /async: returns HTTP status code 200 only when the Patroni node is running as an asynchronous standby.

• GET /asynchronous?lag=<max-lag> or GET /async?lag=<max-lag>: asynchronous standby check endpoint. In addition to checks from asynchronous or async, it also checks replication latency and returns status code 200 only when it is below specified value. The key cluster.last_leader_operation from DCS is used for Leader wal position and compute latency on replica for performance reasons. max-lag can be specified in bytes (integer) or in human readable values, for e.g. 16kB, 64MB, 1GB.

  • GET /async?lag=1048576
  • GET /async?lag=1024kB
  • GET /async?lag=10MB
  • GET /async?lag=1GB

• GET /health: returns HTTP status code 200 only when PostgreSQL is up and running.

• GET /liveness: returns HTTP status code 200 if Patroni heartbeat loop is properly running and 503 if the last run was more than ttl seconds ago on the primary or 2*ttl on the replica. Could be used for livenessProbe.

• GET /readiness?lag=<max-lag>&mode=apply|write: returns HTTP status code 200 when the Patroni node is running as the leader or when PostgreSQL is up, replicating and not too far behind the leader. The lag parameter sets how far a standby is allowed to be behind, and it defaults to maximum_lag_on_failover. Lag can be specified in bytes or in human-readable values, for example 16kB, 64MB, or 1GB. Mode sets whether the WAL needs to be replayed (apply) or just received (write). The default is apply.

  When used as Kubernetes readinessProbe it will make sure freshly started pods only become ready when they have caught up to the leader. This combined with a PodDisruptionBudget will protect against leader being terminated too early during a rolling restart of nodes. It will also make sure that replicas that cannot keep up with replication do not service read-only traffic. The endpoint could be used for readinessProbe when it is not possible to use Kubernetes endpoints for leader elections (OpenShift).

The liveness endpoint is very light-weight and not executing any SQL. Probes should be configured in such a way that they start failing about time when the leader key is expiring. With the default value of ttl, which is 30s example probes would look like:

readinessProbe:
  httpGet:
    scheme: HTTP
    path: /readiness
    port: 8008
  initialDelaySeconds: 3
  periodSeconds: 10
  timeoutSeconds: 5
  successThreshold: 1
  failureThreshold: 3
livenessProbe:
  httpGet:
    scheme: HTTP
    path: /liveness
    port: 8008
  initialDelaySeconds: 3
  periodSeconds: 10
  timeoutSeconds: 5
  successThreshold: 1
  failureThreshold: 3

Monitoring endpoint

The GET /patroni is used by Patroni during the leader race. It also could be used by your monitoring system. The JSON document produced by this endpoint has the same structure as the JSON produced by the health check endpoints.

Example: A healthy cluster

$ curl -s http://localhost:8008/patroni | jq .
{
  "state": "running",
  "postmaster_start_time": "2024-08-28 19:39:26.352526+00:00",
  "role": "primary",
  "server_version": 160004,
  "xlog": {
    "location": 67395656
  },
  "timeline": 1,
  "replication": [
    {
      "usename": "replicator",
      "application_name": "patroni2",
      "client_addr": "10.89.0.6",
      "state": "streaming",
      "sync_state": "async",
      "sync_priority": 0
    },
    {
      "usename": "replicator",
      "application_name": "patroni3",
      "client_addr": "10.89.0.2",
      "state": "streaming",
      "sync_state": "async",
      "sync_priority": 0
    }
  ],
  "dcs_last_seen": 1692356718,
  "tags": {
    "clonefrom": true
  },
  "database_system_identifier": "7268616322854375442",
  "patroni": {
    "version": "4.0.0",
    "scope": "demo",
    "name": "patroni1"
  }
}

Example: An unlocked cluster

$ curl -s http://localhost:8008/patroni  | jq .
{
  "state": "running",
  "postmaster_start_time": "2024-08-28 19:39:26.352526+00:00",
  "role": "replica",
  "server_version": 160004,
  "xlog": {
    "received_location": 67419744,
    "replayed_location": 67419744,
    "replayed_timestamp": null,
    "paused": false
  },
  "timeline": 1,
  "replication": [
    {
      "usename": "replicator",
      "application_name": "patroni2",
      "client_addr": "10.89.0.6",
      "state": "streaming",
      "sync_state": "async",
      "sync_priority": 0
    },
    {
      "usename": "replicator",
      "application_name": "patroni3",
      "client_addr": "10.89.0.2",
      "state": "streaming",
      "sync_state": "async",
      "sync_priority": 0
    }
  ],
  "cluster_unlocked": true,
  "dcs_last_seen": 1692356928,
  "tags": {
    "clonefrom": true
  },
  "database_system_identifier": "7268616322854375442",
  "patroni": {
    "version": "4.0.0",
    "scope": "demo",
    "name": "patroni1"
  }
}

Example: An unlocked cluster with DCS failsafe mode enabled

$ curl -s http://localhost:8008/patroni  | jq .
{
  "state": "running",
  "postmaster_start_time": "2024-08-28 19:39:26.352526+00:00",
  "role": "replica",
  "server_version": 160004,
  "xlog": {
    "location": 67420024
  },
  "timeline": 1,
  "replication": [
    {
      "usename": "replicator",
      "application_name": "patroni2",
      "client_addr": "10.89.0.6",
      "state": "streaming",
      "sync_state": "async",
      "sync_priority": 0
    },
    {
      "usename": "replicator",
      "application_name": "patroni3",
      "client_addr": "10.89.0.2",
      "state": "streaming",
      "sync_state": "async",
      "sync_priority": 0
    }
  ],
  "cluster_unlocked": true,
  "failsafe_mode_is_active": true,
  "dcs_last_seen": 1692356928,
  "tags": {
    "clonefrom": true
  },
  "database_system_identifier": "7268616322854375442",
  "patroni": {
    "version": "4.0.0",
    "scope": "demo",
    "name": "patroni1"
  }
}

Example: A cluster with the pause mode enabled

$ curl -s http://localhost:8008/patroni  | jq .
{
  "state": "running",
  "postmaster_start_time": "2024-08-28 19:39:26.352526+00:00",
  "role": "replica",
  "server_version": 160004,
  "xlog": {
    "location": 67420024
  },
  "timeline": 1,
  "replication": [
    {
      "usename": "replicator",
      "application_name": "patroni2",
      "client_addr": "10.89.0.6",
      "state": "streaming",
      "sync_state": "async",
      "sync_priority": 0
    },
    {
      "usename": "replicator",
      "application_name": "patroni3",
      "client_addr": "10.89.0.2",
      "state": "streaming",
      "sync_state": "async",
      "sync_priority": 0
    }
  ],
  "pause": true,
  "dcs_last_seen": 1724874295,
  "tags": {
    "clonefrom": true
  },
  "database_system_identifier": "7268616322854375442",
  "patroni": {
    "version": "4.0.0",
    "scope": "demo",
    "name": "patroni1"
  }
}

Retrieve the Patroni metrics in Prometheus format through the GET /metrics endpoint.

$ curl http://localhost:8008/metrics

# HELP patroni_version Patroni semver without periods. \
# TYPE patroni_version gauge
patroni_version{scope="batman",name="patroni1"} 040000
# HELP patroni_postgres_running Value is 1 if Postgres is running, 0 otherwise.
# TYPE patroni_postgres_running gauge
patroni_postgres_running{scope="batman",name="patroni1"} 1
# HELP patroni_postmaster_start_time Epoch seconds since Postgres started.
# TYPE patroni_postmaster_start_time gauge
patroni_postmaster_start_time{scope="batman",name="patroni1"} 1724873966.352526
# HELP patroni_primary Value is 1 if this node is the leader, 0 otherwise.
# TYPE patroni_primary gauge
patroni_primary{scope="batman",name="patroni1"} 1
# HELP patroni_xlog_location Current location of the Postgres transaction log, 0 if this node is not the leader.
# TYPE patroni_xlog_location counter
patroni_xlog_location{scope="batman",name="patroni1"} 22320573386952
# HELP patroni_standby_leader Value is 1 if this node is the standby_leader, 0 otherwise.
# TYPE patroni_standby_leader gauge
patroni_standby_leader{scope="batman",name="patroni1"} 0
# HELP patroni_replica Value is 1 if this node is a replica, 0 otherwise.
# TYPE patroni_replica gauge
patroni_replica{scope="batman",name="patroni1"} 0
# HELP patroni_sync_standby Value is 1 if this node is a sync standby replica, 0 otherwise.
# TYPE patroni_sync_standby gauge
patroni_sync_standby{scope="batman",name="patroni1"} 0
# HELP patroni_quorum_standby Value is 1 if this node is a quorum standby replica, 0 otherwise.
# TYPE patroni_quorum_standby gauge
patroni_quorum_standby{scope="batman",name="patroni1"} 0
# HELP patroni_xlog_received_location Current location of the received Postgres transaction log, 0 if this node is not a replica.
# TYPE patroni_xlog_received_location counter
patroni_xlog_received_location{scope="batman",name="patroni1"} 0
# HELP patroni_xlog_replayed_location Current location of the replayed Postgres transaction log, 0 if this node is not a replica.
# TYPE patroni_xlog_replayed_location counter
patroni_xlog_replayed_location{scope="batman",name="patroni1"} 0
# HELP patroni_xlog_replayed_timestamp Current timestamp of the replayed Postgres transaction log, 0 if null.
# TYPE patroni_xlog_replayed_timestamp gauge
patroni_xlog_replayed_timestamp{scope="batman",name="patroni1"} 0
# HELP patroni_xlog_paused Value is 1 if the Postgres xlog is paused, 0 otherwise.
# TYPE patroni_xlog_paused gauge
patroni_xlog_paused{scope="batman",name="patroni1"} 0
# HELP patroni_postgres_streaming Value is 1 if Postgres is streaming, 0 otherwise.
# TYPE patroni_postgres_streaming gauge
patroni_postgres_streaming{scope="batman",name="patroni1"} 1
# HELP patroni_postgres_in_archive_recovery Value is 1 if Postgres is replicating from archive, 0 otherwise.
# TYPE patroni_postgres_in_archive_recovery gauge
patroni_postgres_in_archive_recovery{scope="batman",name="patroni1"} 0
# HELP patroni_postgres_server_version Version of Postgres (if running), 0 otherwise.
# TYPE patroni_postgres_server_version gauge
patroni_postgres_server_version{scope="batman",name="patroni1"} 160004
# HELP patroni_cluster_unlocked Value is 1 if the cluster is unlocked, 0 if locked.
# TYPE patroni_cluster_unlocked gauge
patroni_cluster_unlocked{scope="batman",name="patroni1"} 0
# HELP patroni_failsafe_mode_is_active Value is 1 if failsafe mode is active, 0 otherwise.
# TYPE patroni_failsafe_mode_is_active gauge
patroni_failsafe_mode_is_active{scope="batman",name="patroni1"} 0
# HELP patroni_failsafe_mode_enabled Value is 1 if failsafe_mode is enabled, 0 otherwise.
# TYPE patroni_failsafe_mode_enabled gauge
patroni_failsafe_mode_enabled{scope="batman",name="patroni1"} 0
# HELP patroni_failsafe_member Value is 1 if this node is a member of failsafe, 0 otherwise.
# TYPE patroni_failsafe_member gauge
patroni_failsafe_member{scope="batman",name="patroni1"} 0
# HELP patroni_postgres_timeline Postgres timeline of this node (if running), 0 otherwise.
# TYPE patroni_postgres_timeline gauge
patroni_postgres_timeline{scope="batman",name="patroni1"} 24
# HELP patroni_dcs_last_seen Epoch timestamp when DCS was last contacted successfully by Patroni.
# TYPE patroni_dcs_last_seen gauge
patroni_dcs_last_seen{scope="batman",name="patroni1"} 1724874235
# HELP patroni_pending_restart Value is 1 if the node needs a restart, 0 otherwise.
# TYPE patroni_pending_restart gauge
patroni_pending_restart{scope="batman",name="patroni1"} 1
# HELP patroni_is_paused Value is 1 if auto failover is disabled, 0 otherwise.
# TYPE patroni_is_paused gauge
patroni_is_paused{scope="batman",name="patroni1"} 1
# HELP patroni_postgres_state Numeric representation of Postgres state.
# Values: 0=initdb, 1=initdb_failed, 2=custom_bootstrap, 3=custom_bootstrap_failed, 4=creating_replica, 5=running, 6=starting, 7=bootstrap_starting, 8=start_failed, 9=restarting, 10=restart_failed, 11=stopping, 12=stopped, 13=stop_failed, 14=crashed
# TYPE patroni_postgres_state gauge
patroni_postgres_state{scope="batman",name="patroni1"} 5
# HELP patroni_failover_priority Failover priority of this node.
# TYPE patroni_failover_priority gauge
patroni_failover_priority{scope="batman",name="patroni1"} 1

PostgreSQL State Values

The patroni_postgres_state metric provides a numeric representation of the current PostgreSQL instance state. This is useful for monitoring and alerting systems that need to track state changes over time. The numeric values are generated using the PostgresqlState.get_metrics_description() static method.

PostgreSQL State Values

Cluster status endpoints

• The GET /cluster endpoint generates a JSON document describing the current cluster topology and state:

$ curl -s http://localhost:8008/cluster | jq .
{
  "members": [
    {
      "name": "patroni1",
      "role": "leader",
      "state": "running",
      "api_url": "http://10.89.0.4:8008/patroni",
      "host": "10.89.0.4",
      "port": 5432,
      "timeline": 5,
      "tags": {
        "clonefrom": true
      }
    },
    {
      "name": "patroni2",
      "role": "replica",
      "state": "streaming",
      "api_url": "http://10.89.0.6:8008/patroni",
      "host": "10.89.0.6",
      "port": 5433,
      "timeline": 5,
      "tags": {
        "clonefrom": true
      },
      "receive_lag": 0,
      "receive_lsn": "0/4000060",
      "replay_lag": 0,
      "replay_lsn": "0/4000060",
      "lag": 0,
      "lsn": "0/4000060"
    }
  ],
  "scope": "demo",
  "scheduled_switchover": {
    "at": "2023-09-24T10:36:00+02:00",
    "from": "patroni1",
    "to": "patroni3"
  }
}

• The GET /history endpoint provides a view on the history of cluster switchovers/failovers. The format is very similar to the content of history files in the pg_wal directory. The only difference is the timestamp field showing when the new timeline was created.

$ curl -s http://localhost:8008/history | jq .
[
  [
    1,
    25623960,
    "no recovery target specified",
    "2019-09-23T16:57:57+02:00"
  ],
  [
    2,
    25624344,
    "no recovery target specified",
    "2019-09-24T09:22:33+02:00"
  ],
  [
    3,
    25624752,
    "no recovery target specified",
    "2019-09-24T09:26:15+02:00"
  ],
  [
    4,
    50331856,
    "no recovery target specified",
    "2019-09-24T09:35:52+02:00"
  ]
]

Config endpoint

GET /config: Get the current version of the dynamic configuration:

$ curl -s http://localhost:8008/config | jq .
{
  "ttl": 30,
  "loop_wait": 10,
  "retry_timeout": 10,
  "maximum_lag_on_failover": 1048576,
  "postgresql": {
    "use_slots": true,
    "use_pg_rewind": true,
    "parameters": {
      "hot_standby": "on",
      "wal_level": "hot_standby",
      "max_wal_senders": 5,
      "max_replication_slots": 5,
      "max_connections": "100"
    }
  }
}

PATCH /config: Change the existing configuration.

$ curl -s -XPATCH -d \
    '{"loop_wait":5,"ttl":20,"postgresql":{"parameters":{"max_connections":"101"}}}' \
    http://localhost:8008/config | jq .
{
  "ttl": 20,
  "loop_wait": 5,
  "maximum_lag_on_failover": 1048576,
  "retry_timeout": 10,
  "postgresql": {
    "use_slots": true,
    "use_pg_rewind": true,
    "parameters": {
      "hot_standby": "on",
      "wal_level": "hot_standby",
      "max_wal_senders": 5,
      "max_replication_slots": 5,
      "max_connections": "101"
    }
  }
}

The above REST API call patches the existing configuration and returns the new configuration.

Let’s check that the node processed this configuration. First of all it should start printing log lines every 5 seconds (loop_wait=5). The change of “max_connections” requires a restart, so the “pending_restart” flag should be exposed:

$ curl -s http://localhost:8008/patroni | jq .
{
  "database_system_identifier": "6287881213849985952",
  "postmaster_start_time": "2024-08-28 19:39:26.352526+00:00",
  "xlog": {
    "location": 2197818976
  },
  "timeline": 1,
  "dcs_last_seen": 1724874545,
  "database_system_identifier": "7408277255830290455",
  "pending_restart": true,
  "pending_restart_reason": {
    "max_connections": {
      "old_value": "100",
      "new_value": "101"
    }
  },
  "patroni": {
    "version": "4.0.0",
    "scope": "batman",
    "name": "patroni1"
  },
  "state": "running",
  "role": "primary",
  "server_version": 160004
}

Removing parameters:

If you want to remove (reset) some setting just patch it with null:

$ curl -s -XPATCH -d \
    '{"postgresql":{"parameters":{"max_connections":null}}}' \
    http://localhost:8008/config | jq .
{
  "ttl": 20,
  "loop_wait": 5,
  "retry_timeout": 10,
  "maximum_lag_on_failover": 1048576,
  "postgresql": {
    "use_slots": true,
    "use_pg_rewind": true,
    "parameters": {
      "hot_standby": "on",
      "unix_socket_directories": ".",
      "wal_level": "hot_standby",
      "max_wal_senders": 5,
      "max_replication_slots": 5
    }
  }
}

The above call removes postgresql.parameters.max_connections from the dynamic configuration.

PUT /config: It’s also possible to perform the full rewrite of an existing dynamic configuration unconditionally:

$ curl -s -XPUT -d \
    '{"maximum_lag_on_failover":1048576,"retry_timeout":10,"postgresql":{"use_slots":true,"use_pg_rewind":true,"parameters":{"hot_standby":"on","wal_level":"hot_standby","unix_socket_directories":".","max_wal_senders":5}},"loop_wait":3,"ttl":20}' \
    http://localhost:8008/config | jq .
{
  "ttl": 20,
  "maximum_lag_on_failover": 1048576,
  "retry_timeout": 10,
  "postgresql": {
    "use_slots": true,
    "parameters": {
      "hot_standby": "on",
      "unix_socket_directories": ".",
      "wal_level": "hot_standby",
      "max_wal_senders": 5
    },
    "use_pg_rewind": true
  },
  "loop_wait": 3
}

Switchover and failover endpoints

Switchover

/switchover endpoint only works when the cluster is healthy (there is a leader). It also allows to schedule a switchover at a given time.

When calling /switchover endpoint a candidate can be specified but is not required, in contrast to /failover endpoint. If a candidate is not provided, all the eligible nodes of the cluster will participate in the leader race after the leader stepped down.

In the JSON body of the POST request you must specify the leader field. The candidate and the scheduled_at fields are optional and can be used to schedule a switchover at a specific time.

Depending on the situation, requests might return different HTTP status codes and bodies. Status code 200 is returned when the switchover or failover successfully completed. If the switchover was successfully scheduled, Patroni will return HTTP status code 202. In case something went wrong, the error status code (one of 400, 412, or 503) will be returned with some details in the response body.

DELETE /switchover can be used to delete the currently scheduled switchover.

Example: perform a switchover to any healthy standby

$ curl -s http://localhost:8008/switchover -XPOST -d '{"leader":"postgresql1"}'
Successfully switched over to "postgresql2"

Example: perform a switchover to a specific node

$ curl -s http://localhost:8008/switchover -XPOST -d \
    '{"leader":"postgresql1","candidate":"postgresql2"}'
Successfully switched over to "postgresql2"

Example: schedule a switchover from the leader to any other healthy standby in the cluster at a specific time.

$ curl -s http://localhost:8008/switchover -XPOST -d \
    '{"leader":"postgresql0","scheduled_at":"2019-09-24T12:00+00"}'
Switchover scheduled

Failover

/failover endpoint can be used to perform a manual failover when there are no healthy nodes (e.g. to an asynchronous standby if all synchronous standbys are not healthy enough to promote). However there is no requirement for a cluster not to have leader - failover can also be run on a healthy cluster.

In the JSON body of the POST request you must specify the candidate field. If the leader field is specified, a switchover is triggered instead.

Example:

$ curl -s http://localhost:8008/failover -XPOST -d '{"candidate":"postgresql1"}'
Successfully failed over to "postgresql1"

POST /switchover and POST /failover endpoints are used by patronictl_switchover and patronictl_failover, respectively.

DELETE /switchover is used by patronictl flush cluster-name switchover.

Failover/Switchover comparison

Healthy standby

There are a couple of checks that a member of a cluster should pass to be able to participate in the leader race during a switchover or to become a leader as a failover/switchover candidate:

• be reachable via Patroni API;
• not have nofailover tag set to true;
• have watchdog fully functional (if required by the configuration);
• in case of a switchover in a healthy cluster or an automatic failover, not exceed maximum replication lag (maximum_lag_on_failover configuration parameter);
• in case of a switchover in a healthy cluster or an automatic failover, not have a timeline number smaller than the cluster timeline if check_timeline configuration parameter is set to true;
• in synchronous mode:
  • In case of a switchover (both with and without a candidate): be listed in the /sync key members;
  • For a failover in both healthy and unhealthy clusters, this check is omitted.

Restart endpoint

• POST /restart: You can restart Postgres on the specific node by performing the POST /restart call. In the JSON body of POST request it is possible to optionally specify some restart conditions:
  • restart_pending: boolean, if set to true Patroni will restart PostgreSQL only when restart is pending in order to apply some changes in the PostgreSQL config.
  • role: perform restart only if the current role of the node matches with the role from the POST request.
  • postgres_version: perform restart only if the current version of postgres is smaller than specified in the POST request.
  • timeout: how long we should wait before PostgreSQL starts accepting connections. Overrides primary_start_timeout.
  • schedule: timestamp with time zone, schedule the restart somewhere in the future.
• DELETE /restart: delete the scheduled restart

POST /restart and DELETE /restart endpoints are used by patronictl_restart and patronictl flush cluster-name restart respectively.

Reload endpoint

The POST /reload call will order Patroni to re-read and apply the configuration file. This is the equivalent of sending the SIGHUP signal to the Patroni process. In case you changed some of the Postgres parameters which require a restart (like shared_buffers), you still have to explicitly do the restart of Postgres by either calling the POST /restart endpoint or with the help of patronictl_restart.

The reload endpoint is used by patronictl_reload.

Reinitialize endpoint

POST /reinitialize: reinitialize the PostgreSQL data directory on the specified node. It is allowed to be executed only on replicas. Once called, it will remove the data directory and start pg_basebackup or some alternative replica creation method.

The call might fail if Patroni is in a loop trying to recover (restart) a failed Postgres. In order to overcome this problem one can specify {"force":true} in the request body.

You can specify {“from-leader”:true} in the request body to directly get basebackup from leader node. This is useful when executing reinit during all replica nodes fail.

The reinitialize endpoint is used by patronictl_reinit.

5 - patronictl

Source: https://patroni.readthedocs.io/en/latest/patronictl.html

Patroni has a command-line interface named patronictl, which is used basically to interact with Patroni’s REST API and with the DCS. It is intended to make it easier to perform operations in the cluster, and can easily be used by humans or scripts.

Configuration

patronictl uses 3 sections of the configuration:

• ctl: how to authenticate against the Patroni REST API, and how to validate the server identity. Refer to ctl settings for more details;
• restapi: how to authenticate against the Patroni REST API, and how to validate the server identity. Only used if ctl configuration is not enough. patronictl is mainly interested in restapi.authentication section (in case ctl.authentication is missing) and restapi.cafile setting (in case ctl.cacert is missing). Refer to REST API settings for more details;
• DCS (e.g. etcd): how to contact and authenticate against the DCS used by Patroni.

Those configuration options can come either from environment variables or from a configuration file. Look for the above sections in Environment Configuration Settings or YAML Configuration Settings to understand how you can set the options for them through environment variables or through a configuration file.

If you opt for using environment variables, it’s a straight forward approach. Patronictl will read the environment variables and use their values.

If you opt for using a configuration file, you have different ways to inform patronictl about the file to be used. By default patronictl will attempt to load a configuration file named patronictl.yaml, which is expected to be found under either of these paths, according to your system:

• Mac OS X: ~/Library/Application Support/patroni
• Mac OS X (POSIX): ~/.patroni
• Unix: ~/.config/patroni
• Unix (POSIX): ~/.patroni
• Windows (roaming): C:\Users\<user>\AppData\Roaming\patroni
• Windows (not roaming): C:\Users\<user>\AppData\Local\patroni

You can override that behavior either by:

• Setting the environment variable PATRONICTL_CONFIG_FILE with the path to a custom configuration file;
• Using the -c / --config-file command-line argument of patronictl with the path to a custom configuration file.

Usage

patronictl exposes several handy operations. This section is intended to describe each of them.

Before jumping into each of the sub-commands of patronictl, be aware that patronictl itself has the following command-line arguments:

-c / --config-file
As explained before, used to provide a path to a configuration file for patronictl.

-d / --dcs-url / --dcs
Provide a connection string to the DCS used by Patroni.

This argument can be used either to override the DCS and namespace settings from the patronictl configuration, or to define it if it’s missing in the configuration.

The value should be in the format DCS://HOST:PORT/NAMESPACE, e.g. etcd3://localhost:2379/service to connect to etcd v3 running on localhost with Patroni cluster stored under service namespace. Any part that is missing in the argument value will be replaced with the value present in the configuration or with its default.

-k / --insecure
Flag to bypass validation of REST API server SSL certificate.

This is the synopsis for running a command from the patronictl:

patronictl [ { -c | --config-file } CONFIG_FILE ]
  [ { -d | --dcs-url | --dcs } DCS_URL ]
  [ { -k | --insecure } ]
  SUBCOMMAND

In the following sub-sections you can find a description of each command implemented by patronictl. For sake of example, we will use the configuration files present in the GitHub repository of Patroni (files postgres0.yml, postgres1.yml and postgres2.yml).

patronictl demote-cluster

Synopsis

demote-cluster
  [ CLUSTER_NAME ]
  [ --host HOST ]
  [ --port PORT ]
  [ --restore-command RESTORE_COMMAND ]
  [ --primary-slot-name PRIMARY_SLOT_NAME ]
  [ --force ]

Description

patronictl demote-cluster converts a regular Patroni cluster into a standby cluster.

The command patches the dynamic configuration with a standby_cluster section built from the provided remote primary connection options, then waits until the leader is running as a standby leader. It prints the current cluster topology before changing the configuration and asks for confirmation unless --force is used.

At least one of --host, --port or --restore-command must be specified.

Parameters

CLUSTER_NAME: Name of the Patroni cluster.

If not given, patronictl will attempt to fetch that from the scope configuration, if it exists.

--host: Address of the remote node.

--port: Port of the remote node.

--restore-command: Command to restore WAL records from the remote primary.

--primary-slot-name: Name of the replication slot on the remote node to use for replication.

--force: Flag to skip confirmation prompts when demoting the cluster.

Useful for scripts.

Examples

Demote the cluster to a standby cluster that follows a remote primary endpoint:

$ patronictl -c postgres0.yml demote-cluster batman --host 192.0.2.10 --port 5432 --primary-slot-name batman --force

patronictl dsn

Synopsis

dsn
  [ CLUSTER_NAME ]
  [ { { -r | --role } { leader | primary | standby-leader | replica | standby | any } | { -m | --member } MEMBER_NAME } ]
  [ --group CITUS_GROUP ]

Description

patronictl dsn gets the connection string for one member of the Patroni cluster.

If multiple members match the parameters of this command, one of them will be chosen, prioritizing the primary node.

Parameters

CLUSTER_NAME: Name of the Patroni cluster.

If not given, patronictl will attempt to fetch that from the scope configuration, if it exists.

-r / --role
Choose a member that has the given role.

Role can be one of:

• leader: the leader of either a regular Patroni cluster or a standby Patroni cluster; or
• primary: the leader of a regular Patroni cluster; or
• standby-leader: the leader of a standby Patroni cluster; or
• replica: a replica of a Patroni cluster; or
• standby: same as replica; or
• any: any role. Same as omitting this parameter; or

-m / --member
Choose a member of the cluster with the given name.

MEMBER_NAME is the name of the member.

--group
Choose a member that is part of the given Citus group.

CITUS_GROUP is the ID of the Citus group.

Examples

Get DSN of the primary node:

$ patronictl -c postgres0.yml dsn batman -r primary
host=127.0.0.1 port=5432

Get DSN of the node named postgresql1:

$ patronictl -c postgres0.yml dsn batman --member postgresql1
host=127.0.0.1 port=5433

patronictl edit-config

Synopsis

edit-config
  [ CLUSTER_NAME ]
  [ --group CITUS_GROUP ]
  [ { -q | --quiet } ]
  [ { -s | --set } CONFIG="VALUE" [, ... ] ]
  [ { -p | --pg } PG_CONFIG="PG_VALUE" [, ... ] ]
  [ { --apply | --replace } CONFIG_FILE ]
  [ --force ]

Description

patronictl edit-config changes the dynamic configuration of the cluster and updates the DCS with that.

Parameters

CLUSTER_NAME: Name of the Patroni cluster.

If not given, patronictl will attempt to fetch that from the scope configuration, if it exists.

--group
Change dynamic configuration of the given Citus group.

If not given, patronictl will attempt to fetch that from the citus.group configuration, if it exists.

CITUS_GROUP is the ID of the Citus group.

-q / --quiet
Flag to skip showing the configuration diff.

-s / --set
Set a given dynamic configuration option with a given value.

CONFIG is the name of the dynamic configuration path in the YAML tree, with levels joined by . .

VALUE is the value for CONFIG. If it is null, then CONFIG will be removed from the dynamic configuration.

-p / --pg
Set a given dynamic Postgres configuration option with the given value.

It is essentially a shorthand for --s / --set with CONFIG prepended with postgresql.parameters..

PG_CONFIG is the name of the Postgres configuration to be set.

PG_VALUE is the value for PG_CONFIG. If it is null, then PG_CONFIG will be removed from the dynamic configuration.

--apply
Apply dynamic configuration from the given file.

It is similar to specifying multiple -s / --set options, one for each configuration from CONFIG_FILE.

CONFIG_FILE is the path to a file containing the dynamic configuration to be applied, in YAML format. Use - if you want to read from stdin.

--replace
Replace the dynamic configuration in the DCS with the dynamic configuration specified in the given file.

CONFIG_FILE is the path to a file containing the new dynamic configuration to take effect, in YAML format. Use - if you want to read from stdin.

--force
Flag to skip confirmation prompts when changing the dynamic configuration.

Useful for scripts.

Examples

Change max_connections Postgres GUC:

patronictl -c postgres0.yml edit-config batman --pg max_connections="150" --force
---
+++
@@ -1,6 +1,8 @@
loop_wait: 10
maximum_lag_on_failover: 1048576
postgresql:
+  parameters:
+    max_connections: 150
  pg_hba:
  - host replication replicator 127.0.0.1/32 md5
  - host all all 0.0.0.0/0 md5

Configuration changed

Change loop_wait and ttl settings:

patronictl -c postgres0.yml edit-config batman --set loop_wait="15" --set ttl="45" --force
---
+++
@@ -1,4 +1,4 @@
-loop_wait: 10
+loop_wait: 15
maximum_lag_on_failover: 1048576
postgresql:
  pg_hba:
@@ -6,4 +6,4 @@
  - host all all 0.0.0.0/0 md5
  use_pg_rewind: true
retry_timeout: 10
-ttl: 30
+ttl: 45

Configuration changed

Remove maximum_lag_on_failover setting from dynamic configuration:

patronictl -c postgres0.yml edit-config batman --set maximum_lag_on_failover="null" --force
---
+++
@@ -1,5 +1,4 @@
loop_wait: 10
-maximum_lag_on_failover: 1048576
postgresql:
  pg_hba:
  - host replication replicator 127.0.0.1/32 md5

Configuration changed

patronictl failover

Synopsis

failover
  [ CLUSTER_NAME ]
  [ --group CITUS_GROUP ]
  --candidate CANDIDATE_NAME
  [ --force ]

Description

patronictl failover performs a manual failover in the cluster.

It is designed to be used when the cluster is not healthy, e.g.:

• There is no leader; or
• There is no synchronous standby available in a synchronous cluster.

It also allows to fail over to an asynchronous node if synchronous mode is enabled.

Parameters

CLUSTER_NAME: Name of the Patroni cluster.

If not given, patronictl will attempt to fetch that from the scope configuration, if it exists.

--group
Perform a failover in the given Citus group.

CITUS_GROUP is the ID of the Citus group.

--candidate
The node to be promoted on failover.

CANDIDATE_NAME is the name of the node to be promoted.

--force
Flag to skip confirmation prompts when performing the failover.

Useful for scripts.

Examples

Fail over to node postgresql2:

$ patronictl -c postgres0.yml failover batman --candidate postgresql2 --force
Current cluster topology
+ Cluster: batman (7277694203142172922) -+-----------+----+-------------+-----+------------+-----+
| Member      | Host           | Role    | State     | TL | Receive LSN | Lag | Replay LSN | Lag |
+-------------+----------------+---------+-----------+----+-------------+-----+------------+-----+
| postgresql0 | 127.0.0.1:5432 | Leader  | running   |  3 |             |     |            |     |
| postgresql1 | 127.0.0.1:5433 | Replica | streaming |  3 |   0/40004E8 |   0 |  0/40004E8 |   0 |
| postgresql2 | 127.0.0.1:5434 | Replica | streaming |  3 |   0/40004E8 |   0 |  0/40004E8 |   0 |
+-------------+----------------+---------+-----------+----+-------------+-----+------------+-----+
2023-09-12 11:52:27.50978 Successfully failed over to "postgresql2"
+ Cluster: batman (7277694203142172922) -+---------+----+-------------+---------+------------+---------+
| Member      | Host           | Role    | State   | TL | Receive LSN |     Lag | Replay LSN |     Lag |
+-------------+----------------+---------+---------+----+-------------+---------+------------+---------+
| postgresql0 | 127.0.0.1:5432 | Replica | stopped |    |     unknown | unknown |    unknown | unknown |
| postgresql1 | 127.0.0.1:5433 | Replica | running |  3 |   0/4000188 |       0 |  0/4000188 |       0 |
| postgresql2 | 127.0.0.1:5434 | Leader  | running |  3 |             |         |            |         |
+-------------+----------------+---------+---------+----+-------------+---------+------------+---------+

patronictl flush

Synopsis

flush
  CLUSTER_NAME
  [ MEMBER_NAME [, ... ] ]
  { restart | switchover }
  [ --group CITUS_GROUP ]
  [ { -r | --role } { leader | primary | standby-leader | replica | standby | any } ]
  [ --force ]

Description

patronictl flush discards scheduled events, if any.

Parameters

CLUSTER_NAME
Name of the Patroni cluster.

MEMBER_NAME
Discard scheduled events for the given Patroni member(s).

Multiple members can be specified. If no members are specified, all of them are considered.

restart
Discard scheduled restart events.

switchover
Discard scheduled switchover event.

--group
Discard scheduled events from the given Citus group.

CITUS_GROUP is the ID of the Citus group.

-r / --role
Discard scheduled events for members that have the given role.

Role can be one of:

• leader: the leader of either a regular Patroni cluster or a standby Patroni cluster; or
• primary: the leader of a regular Patroni cluster; or
• standby-leader: the leader of a standby Patroni cluster; or
• replica: a replica of a Patroni cluster; or
• standby: same as replica; or
• any: any role. Same as omitting this parameter.

--force
Flag to skip confirmation prompts when performing the flush.

Useful for scripts.

Examples

Discard a scheduled switchover event:

$ patronictl -c postgres0.yml flush batman switchover --force
Success: scheduled switchover deleted

Discard scheduled restart of all standby nodes:

$ patronictl -c postgres0.yml flush batman restart -r replica --force
+ Cluster: batman (7277694203142172922) -+-----------+----+-------------+-----+------------+-----+---------------------------+
| Member      | Host           | Role    | State     | TL | Receive LSN | Lag | Replay LSN | Lag | Scheduled restart         |
+-------------+----------------+---------+-----------+----+-------------+-----+------------+-----+---------------------------+
| postgresql0 | 127.0.0.1:5432 | Leader  | running   |  5 |             |     |            |     | 2025-03-23T18:00:00-03:00 |
| postgresql1 | 127.0.0.1:5433 | Replica | streaming |  5 |   0/4000400 |   0 |  0/4000400 |   0 | 2025-03-23T18:00:00-03:00 |
| postgresql2 | 127.0.0.1:5434 | Replica | streaming |  5 |   0/4000400 |   0 |  0/4000400 |   0 | 2025-03-23T18:00:00-03:00 |
+-------------+----------------+---------+-----------+----+-------------+-----+------------+-----+---------------------------+
Success: flush scheduled restart for member postgresql1
Success: flush scheduled restart for member postgresql2

Discard scheduled restart of nodes postgresql0 and postgresql1:

$ patronictl -c postgres0.yml flush batman postgresql0 postgresql1 restart --force
+ Cluster: batman (7277694203142172922) -+-----------+----+-------------+-----+------------+-----+---------------------------+
| Member      | Host           | Role    | State     | TL | Receive LSN | Lag | Replay LSN | Lag | Scheduled restart         |
+-------------+----------------+---------+-----------+----+-------------+-----+------------+-----+---------------------------+
| postgresql0 | 127.0.0.1:5432 | Leader  | running   |  5 |             |     |            |     | 2025-03-23T18:00:00-03:00 |
| postgresql1 | 127.0.0.1:5433 | Replica | streaming |  5 |   0/4000400 |   0 |  0/4000400 |   0 | 2025-03-23T18:00:00-03:00 |
| postgresql2 | 127.0.0.1:5434 | Replica | streaming |  5 |   0/4000400 |   0 |  0/4000400 |   0 | 2025-03-23T18:00:00-03:00 |
+-------------+----------------+---------+-----------+----+-------------+-----+------------+-----+---------------------------+
Success: flush scheduled restart for member postgresql0
Success: flush scheduled restart for member postgresql1

patronictl history

Synopsis

history
  [ CLUSTER_NAME ]
  [ --group CITUS_GROUP ]
  [ { -f | --format } { pretty | tsv | json | yaml } ]

Description

patronictl history shows a history of failover and switchover events from the cluster, if any.

The following information is included in the output:

TL
Postgres timeline at which the event occurred.

LSN
Postgres LSN at which the event occurred.

Reason
Reason fetched from the Postgres .history file.

Timestamp
Time when the event occurred.

New Leader
Patroni member that has been promoted during the event.

Parameters

CLUSTER_NAME
Name of the Patroni cluster.

If not given, patronictl will attempt to fetch that from the scope configuration, if it exists.

--group
Show history of events from the given Citus group.

CITUS_GROUP is the ID of the Citus group.

If not given, patronictl will attempt to fetch that from the citus.group configuration, if it exists.

-f / --format
How to format the list of events in the output.

Format can be one of:

• pretty: prints history as a pretty table; or
• tsv: prints history as tabular information, with columns delimited by \t; or
• json: prints history in JSON format; or
• yaml: prints history in YAML format.

The default is pretty.

--force
Flag to skip confirmation prompts when performing the flush.

Useful for scripts.

Examples

Show the history of events:

$ patronictl -c postgres0.yml history batman
+----+----------+------------------------------+----------------------------------+-------------+
| TL |      LSN | Reason                       | Timestamp                        | New Leader  |
+----+----------+------------------------------+----------------------------------+-------------+
|  1 | 24392648 | no recovery target specified | 2023-09-11T22:11:27.125527+00:00 | postgresql0 |
|  2 | 50331864 | no recovery target specified | 2023-09-12T11:34:03.148097+00:00 | postgresql0 |
|  3 | 83886704 | no recovery target specified | 2023-09-12T11:52:26.948134+00:00 | postgresql2 |
|  4 | 83887280 | no recovery target specified | 2023-09-12T11:53:09.620136+00:00 | postgresql0 |
+----+----------+------------------------------+----------------------------------+-------------+

Show the history of events in YAML format:

$ patronictl -c postgres0.yml history batman -f yaml
- LSN: 24392648
  New Leader: postgresql0
  Reason: no recovery target specified
  TL: 1
  Timestamp: '2023-09-11T22:11:27.125527+00:00'
- LSN: 50331864
  New Leader: postgresql0
  Reason: no recovery target specified
  TL: 2
  Timestamp: '2023-09-12T11:34:03.148097+00:00'
- LSN: 83886704
  New Leader: postgresql2
  Reason: no recovery target specified
  TL: 3
  Timestamp: '2023-09-12T11:52:26.948134+00:00'
- LSN: 83887280
  New Leader: postgresql0
  Reason: no recovery target specified
  TL: 4
  Timestamp: '2023-09-12T11:53:09.620136+00:00'

patronictl list

Synopsis

list
  [ CLUSTER_NAME [, ... ] ]
  [ --group CITUS_GROUP ]
  [ { -e | --extended } ]
  [ { -t | --timestamp } ]
  [ { -f | --format } { pretty | tsv | json | yaml } ]
  [ { -W | { -w | --watch } TIME } ]

Description

patronictl list shows information about Patroni cluster and its members.

The following information is included in the output:

Cluster
Name of the Patroni cluster.

Member
Name of the Patroni member.

Host
Host where the member is located.

Role
Current role of the member.

Can be one among:

• Leader: the current leader of a regular Patroni cluster; or
• Standby Leader: the current leader of a Patroni standby cluster; or
• Sync Standby: a synchronous standby of a Patroni cluster with synchronous mode enabled; or
• Replica: a regular standby of a Patroni cluster.

State
Current state of Postgres in the Patroni member.

Some examples among the possible states:

• running: if Postgres is currently up and running;
• streaming: if a replica and Postgres is currently streaming WALs from the primary node;
• in archive recovery: if a replica and Postgres is currently fetching WALs from the archive;
• stopped: if Postgres had been shut down;
• crashed: if Postgres has crashed.

TL
Current Postgres timeline in the Patroni member.

Receive LSN
The last write-ahead log location received and synced to disk by streaming replication of the member (pg_catalog.pg_last_(xlog|wal)_receive_(location|lsn)()).

Receive Lag
Replication lag between the Receive LSN position of the member and its upstream in MB.

Replay LSN
The last write-ahead log location replayed during recovery of the member (pg_catalog.pg_last_(xlog|wal)_replay_(location|lsn)()).

Replay Lag
Replication lag between the Replay LSN position of the member and its upstream in MB.

Besides that, the following information may be included in the output:

System identifier
Postgres system identifier.

Group
Citus group ID.

Pending restart
* indicates that the node needs a restart for some Postgres configuration to take effect. An empty value indicates the node does not require a restart.

Scheduled restart
Timestamp at which a restart has been scheduled for the Postgres instance managed by the Patroni member. An empty value indicates there is no scheduled restart for the member.

Tags
Contains tags set for the Patroni member. An empty value indicates that either no tags have been configured, or that they have been configured with default values.

Scheduled switchover
Timestamp at which a switchover has been scheduled for the Patroni cluster, if any.

Maintenance mode

If the cluster monitoring is currently paused.

Note

Shown in the table footer.

Only shown if the cluster is paused, and output format is pretty.

Parameters

CLUSTER_NAME
Name of the Patroni cluster.

If not given, patronictl will attempt to fetch that from the scope configuration, if it exists.

--group
Show information about members from the given Citus group.

CITUS_GROUP is the ID of the Citus group.

-e / --extended
Show extended information.

Force showing Pending restart, Scheduled restart and Tags attributes, even if their value is empty.

-t / --timestamp
Print timestamp before printing information about the cluster and its members.

-f / --format
How to format the list of events in the output.

Format can be one of:

• pretty: prints history as a pretty table; or
• tsv: prints history as tabular information, with columns delimited by \t; or
• json: prints history in JSON format; or
• yaml: prints history in YAML format.

The default is pretty.

-W
Automatically refresh information every 2 seconds.

-w / --watch
Automatically refresh information at the specified interval.

TIME is the interval between refreshes, in seconds.

Examples

Show information about the cluster in pretty format:

$ patronictl -c postgres0.yml list batman
+ Cluster: batman (7277694203142172922) -+-----------+----+-------------+-----+------------+-----+
| Member      | Host           | Role    | State     | TL | Receive LSN | Lag | Replay LSN | Lag |
+-------------+----------------+---------+-----------+----+-------------+-----+------------+-----+
| postgresql0 | 127.0.0.1:5432 | Leader  | running   |  5 |             |     |            |     |
| postgresql1 | 127.0.0.1:5433 | Replica | streaming |  5 |   0/40004E8 |   0 |  0/40004E8 |   0 |
| postgresql2 | 127.0.0.1:5434 | Replica | streaming |  5 |   0/40004E8 |   0 |  0/40004E8 |   0 |
+-------------+----------------+---------+-----------+----+-------------+-----+------------+-----+

Show information about the cluster in pretty format with extended columns:

$ patronictl -c postgres0.yml list batman -e
+ Cluster: batman (7277694203142172922) -+-----------+----+-------------+-----+------------+-----+-----------------+------------------------+-------------------+------+
| Member      | Host           | Role    | State     | TL | Receive LSN | Lag | Replay LSN | Lag | Pending restart | Pending restart reason | Scheduled restart | Tags |
+-------------+----------------+---------+-----------+----+-------------+-----+------------+-----+-----------------+------------------------+-------------------+------+
| postgresql0 | 127.0.0.1:5432 | Leader  | running   |  5 |             |     |            |     |                 |                        |                   |      |
| postgresql1 | 127.0.0.1:5433 | Replica | streaming |  5 |   0/40004E8 |   0 |  0/40004E8 |   0 |                 |                        |                   |      |
| postgresql2 | 127.0.0.1:5434 | Replica | streaming |  5 |   0/40004E8 |   0 |  0/40004E8 |   0 |                 |                        |                   |      |
+-------------+----------------+---------+-----------+----+-------------+-----+------------+-----+-----------------+------------------------+-------------------+------+

Show information about the cluster in YAML format, with timestamp of execution:

$ patronictl -c postgres0.yml list batman -f yaml -t
2023-09-12 13:30:48
- Cluster: batman
  Host: 127.0.0.1:5432
  Member: postgresql0
  Role: Leader
  State: running
  TL: 5
- Cluster: batman
  Host: 127.0.0.1:5433
  Receive LSN: 0/40004E8
  Receive Lag: 0
  Replay LSN: 0/40004E8
  Replay Lag: 0
  Member: postgresql1
  Role: Replica
  State: streaming
  TL: 5
- Cluster: batman
  Host: 127.0.0.1:5434
  Receive LSN: 0/40004E8
  Receive Lag: 0
  Replay LSN: 0/40004E8
  Replay Lag: 0
  Member: postgresql2
  Role: Replica
  State: streaming
  TL: 5

patronictl pause

Synopsis

pause
  [ CLUSTER_NAME ]
  [ --group CITUS_GROUP ]
  [ --wait ]

Description

patronictl pause temporarily puts the Patroni cluster in maintenance mode and disables automatic failover.

Parameters

CLUSTER_NAME
Name of the Patroni cluster.

If not given, patronictl will attempt to fetch that from the scope configuration, if it exists.

--group
Pause the given Citus group.

CITUS_GROUP is the ID of the Citus group.

If not given, patronictl will attempt to fetch that from the citus.group configuration, if it exists.

--wait
Wait until all Patroni members are paused before returning control to the caller.

Examples

Put the cluster in maintenance mode, and wait until all nodes have been paused:

$ patronictl -c postgres0.yml pause batman --wait
'pause' request sent, waiting until it is recognized by all nodes
Success: cluster management is paused

patronictl promote-cluster

Synopsis

promote-cluster
  [ CLUSTER_NAME ]
  [ --force ]

Description

patronictl promote-cluster converts a standby cluster into a regular Patroni cluster.

The command removes the standby_cluster section from the dynamic configuration and waits until the leader is running as the primary. It prints the current cluster topology before changing the configuration and asks for confirmation unless --force is used.

Parameters

CLUSTER_NAME: Name of the Patroni cluster.

If not given, patronictl will attempt to fetch that from the scope configuration, if it exists.

--force: Flag to skip confirmation prompts when promoting the cluster.

Useful for scripts.

Examples

Promote the standby cluster to run as a regular Patroni cluster:

$ patronictl -c postgres0.yml promote-cluster batman --force

patronictl query

Synopsis

query
  [ CLUSTER_NAME ]
  [ --group CITUS_GROUP ]
  [ { { -r | --role } { leader | primary | standby-leader | replica | standby | any } | { -m | --member } MEMBER_NAME } ]
  [ { -d | --dbname } DBNAME ]
  [ { -U | --username } USERNAME ]
  [ --password ]
  [ --format { pretty | tsv | json | yaml } ]
  [ { { -f | --file } FILE_NAME | { -c | --command } SQL_COMMAND } ]
  [ --delimiter ]
  [ { -W | { -w | --watch } TIME } ]

Description

patronictl query executes a SQL command or script against a member of the Patroni cluster.

Parameters

CLUSTER_NAME
Name of the Patroni cluster.

If not given, patronictl will attempt to fetch that from the scope configuration, if it exists.

--group
Query the given Citus group.

CITUS_GROUP is the ID of the Citus group.

-r / --role
Choose a member that has the given role.

Role can be one of:

• leader: the leader of either a regular Patroni cluster or a standby Patroni cluster; or
• primary: the leader of a regular Patroni cluster; or
• standby-leader: the leader of a standby Patroni cluster; or
• replica: a replica of a Patroni cluster; or
• standby: same as replica; or
• any: any role. Same as omitting this parameter.

-m / --member
Choose a member that has the given name.

MEMBER_NAME is the name of the member to be picked.

-d / --dbname
Database to connect and run the query.

DBNAME is the name of the database. If not given, defaults to USERNAME.

-U / --username
User to connect to the database.

USERNAME name of the user. If not given, defaults to the operating system user running patronictl query.

--password
Prompt for the password of the connecting user.

As Patroni uses libpq, alternatively you can create a ~/.pgpass file or set the PGPASSWORD environment variable.

--format
How to format the output of the query.

Format can be one of:

• pretty: prints query output as a pretty table; or
• tsv: prints query output as tabular information, with columns delimited by \t; or
• json: prints query output in JSON format; or
• yaml: prints query output in YAML format.

The default is tsv.

-f / --file
Use a file as source of commands to run queries.

FILE_NAME is the path to the source file.

-c / --command
Run the given SQL command in the query.

SQL_COMMAND is the SQL command to be executed.

--delimiter
The delimiter when printing information in tsv format, or \t if omitted.

-W
Automatically re-run the query every 2 seconds.

-w / --watch
Automatically re-run the query at the specified interval.

TIME is the interval between re-runs, in seconds.

Examples

Run a SQL command as postgres user, and ask for its password:

$ patronictl -c postgres0.yml query batman -U postgres --password -c "SELECT now()"
Password:
now
2023-09-12 18:10:53.228084+00:00

Run a SQL command as postgres user, and take password from libpq environment variable:

$ PGPASSWORD=patroni patronictl -c postgres0.yml query batman -U postgres -c "SELECT now()"
now
2023-09-12 18:11:37.639500+00:00

Run a SQL command and print in pretty format every 2 seconds:

$ patronictl -c postgres0.yml query batman -c "SELECT now()" --format pretty -W
+----------------------------------+
| now                              |
+----------------------------------+
| 2023-09-12 18:12:16.716235+00:00 |
+----------------------------------+
+----------------------------------+
| now                              |
+----------------------------------+
| 2023-09-12 18:12:18.732645+00:00 |
+----------------------------------+
+----------------------------------+
| now                              |
+----------------------------------+
| 2023-09-12 18:12:20.750573+00:00 |
+----------------------------------+

Run a SQL command on database test and print the output in YAML format:

$ patronictl -c postgres0.yml query batman -d test -c "SELECT now() AS column_1, 'test' AS column_2" --format yaml
- column_1: 2023-09-12 18:14:22.052060+00:00
  column_2: test

Run a SQL command on member postgresql2:

$ patronictl -c postgres0.yml query batman -m postgresql2 -c "SHOW port"
port
5434

Run a SQL command on any of the standbys:

$ patronictl -c postgres0.yml query batman -r replica -c "SHOW port"
port
5433

patronictl reinit

Synopsis

reinit
  CLUSTER_NAME
  [ MEMBER_NAME [, ... ] ]
  [ --group CITUS_GROUP ]
  [ --wait ]
  [ --force ]
  [ --from-leader ]

Description

patronictl reinit rebuilds a Postgres standby instance managed by a replica member of the Patroni cluster.

Parameters

CLUSTER_NAME
Name of the Patroni cluster.

MEMBER_NAME
Name of the replica member for which the Postgres instance will be rebuilt.

Multiple replica members can be specified. If no members are specified, the command does nothing.

--group
Rebuild a replica member of the given Citus group.

CITUS_GROUP is the ID of the Citus group.

--wait
Wait until the reinitialization of the Postgres standby node(s) is finished.

--force
Flag to skip confirmation prompts when rebuilding Postgres standby instances.

--from-leader
Flag to get basebackup from leader directly.

Useful for scripts.

Examples

Request a rebuild of all replica members of the Patroni cluster and immediately return control to the caller:

$ patronictl -c postgres0.yml reinit batman postgresql1 postgresql2 --force
+ Cluster: batman (7277694203142172922) -+-----------+----+-------------+-----+------------+-----+
| Member      | Host           | Role    | State     | TL | Receive LSN | Lag | Replay LSN | Lag |
+-------------+----------------+---------+-----------+----+-------------+-----+------------+-----+
| postgresql0 | 127.0.0.1:5432 | Leader  | running   |  5 |             |     |            |     |
| postgresql1 | 127.0.0.1:5433 | Replica | streaming |  5 |   0/40004E8 |   0 |  0/40004E8 |   0 |
| postgresql2 | 127.0.0.1:5434 | Replica | streaming |  5 |   0/40004E8 |   0 |  0/40004E8 |   0 |
+-------------+----------------+---------+-----------+----+-------------+-----+------------+-----+
Success: reinitialize for member postgresql1
Success: reinitialize for member postgresql2

Request a rebuild of postgresql2 and wait for it to complete:

$ patronictl -c postgres0.yml reinit batman postgresql2 --wait --force
+ Cluster: batman (7277694203142172922) -+-----------+----+-------------+-----+------------+-----+
| Member      | Host           | Role    | State     | TL | Receive LSN | Lag | Replay LSN | Lag |
+-------------+----------------+---------+-----------+----+-------------+-----+------------+-----+
| postgresql0 | 127.0.0.1:5432 | Leader  | running   |  5 |             |     |            |     |
| postgresql1 | 127.0.0.1:5433 | Replica | streaming |  5 |   0/40004E8 |   0 |  0/40004E8 |   0 |
| postgresql2 | 127.0.0.1:5434 | Replica | streaming |  5 |   0/40004E8 |   0 |  0/40004E8 |   0 |
+-------------+----------------+---------+-----------+----+-------------+-----+------------+-----+
Success: reinitialize for member postgresql2
Waiting for reinitialize to complete on: postgresql2
Reinitialize is completed on: postgresql2

Request a rebuild of postgresql2 and get basebackup from leader directly:

$ patronictl -c postgres0.yml reinit batman postgresql2 --from-leader
+ Cluster: batman (7277694203142172922) -+-----------+----+-------------+-----+------------+-----+
| Member      | Host           | Role    | State     | TL | Receive LSN | Lag | Replay LSN | Lag |
+-------------+----------------+---------+-----------+----+-------------+-----+------------+-----+
| postgresql0 | 127.0.0.1:5432 | Leader  | running   |  5 |             |     |            |     |
| postgresql1 | 127.0.0.1:5433 | Replica | streaming |  5 |   0/40004E8 |   0 |  0/40004E8 |   0 |
| postgresql2 | 127.0.0.1:5434 | Replica | streaming |  5 |   0/40004E8 |   0 |  0/40004E8 |   0 |
+-------------+----------------+---------+-----------+----+-------------+-----+------------+-----+
Success: reinitialize for member postgresql2

patronictl reload

Synopsis

reload
  CLUSTER_NAME
  [ MEMBER_NAME [, ... ] ]
  [ --group CITUS_GROUP ]
  [ { -r | --role } { leader | primary | standby-leader | replica | standby | any } ]
  [ --force ]

Description

patronictl reload requests a reload of local configuration for one or more Patroni members.

It also triggers pg_ctl reload on the managed Postgres instance, even if nothing has changed.
